Molex Right Angle Surface PCB Socket 10-Contact 2 Row 1.5 mm Pitch Surface Mount 503148-1090

The Molex 503148-1090 Right Angle Surface PCB Socket is a precision-engineered connector designed for electronic applications requiring reliable wire-to-board connections.

Featuring 10 contacts in a 2-row configuration with a 1.5 mm pitch and a right angle orientation, this PCB socket provides a secure surface mount termination suitable for automated assembly.

The contacts are made from durable copper alloy and plated with tin to ensure stable electrical conductivity and resistance to corrosion. Its beige coloured body enables simple visual identification on printed circuit boards.

Rated for a voltage of 100V and current of 1A, this socket operates efficiently within a temperature range of -40°C to 105°C, making it suitable for various industrial and commercial electronic applications.

The stacking height of 9.2 mm allows it to fit into compact PCB layouts while maintaining robust mechanical performance. Manufactured in Japan, this product maintains high quality standards though it does not carry specific standards or approvals.

Rated for 100V voltage and 1A current capacity. Right angle orientation with surface mount termination. Copper alloy contacts plated with tin for durability. Operating temperature range from -40°C to 105°C. 10 contacts arranged in 2 rows with 1.5 mm pitch.

Stacking height of 9.2 mm for compact assembly. Wire-to-board connector system. Beige coloured body for easy identification. Manufactured in Japan for quality assurance. This PCB Socket is suited for industrial electronics, manufacturing equipment, and high-reliability electrical systems where precise and stable connections are essential.
