| Country of Origin | India |
|---|---|
| Brand | Nexperia |
| Model | PDTC143XQC-QZ |
| Mount Type | Surface |
| Series | PDTC143X |
| Maximum Operating Temperature | 150°C |
| Package Type | DFN1412D-3 |
| Minimum Operating Temperature | -55°C |
| Standards/Approvals | RoHS |
| Pin Count | 3 |
| Maximum Collector Emitter Voltage Vceo | 50V |
| Minimum DC Current Gain hFE | 50 |
| Transistor Polarity | NPN |
| Maximum Emitter Base Voltage VEBO | 7V |
| Maximum Collector Base Voltage VCBO | 50V |
| Automotive Standard | AEC-Q101 |
| Maximum DC Collector Current Idc | 100mA |
| Transistor Configuration | NPN |
| Maximum Transition Frequency ft | 230MHz |
The Nexperia PDTC143XQC-QZ is a resistor-equipped NPN transistor designed specifically for compact and efficient surface mount applications. It features a maximum DC collector current of 100 mA and a collector-emitter voltage rating of 50 V within an ultra-small DFN1412D-3 (SOT8009) 3-pin leadless plastic package. This package includes side-wettable flanks and a low height of 0.5 mm, making it suitable for high-density circuit boards and automated assembly processes.
Integrated resistors simplify the overall circuit design and reduce the number of discrete components, which lowers manufacturing costs and assembly complexity. The transistor offers a minimum DC current gain (hFE) of 50 and a high transition frequency of 230 MHz, making it well-suited for digital switching and signal amplification applications.
Operating temperatures range from -55°C to 150°C, ensuring robust performance in harsh environments. Its automotive-grade qualification under AEC-Q101 standard guarantees reliability for automotive and industrial use cases.
This resistor-equipped transistor is a cost-effective alternative to traditional BC857 series transistors for digital electronics, switching loads, and controlling integrated circuit inputs while reducing board space. Its 3-pin DFN1412D-3 surface mount package facilitates automated manufacturing and optical inspection, making it ideal for modern electronics production lines.
Supports a maximum DC collector current of 100 mA. Maximum collector-emitter voltage rating is 50 V. Comes in ultra small 3-pin DFN1412D-3 plastic package with side-wettable flanks. Built-in resistors simplify circuit design and reduce component count.
Low package height of 0.5 mm suitable for automated optical inspection. Maximum operating temperature of 150°C and minimum of -55°C. Minimum current gain (hFE) of 50 ensures reliable performance. Complies with RoHS and automotive standard AEC-Q101.
Ideal for digital applications, switch load control, and controlling IC inputs.
Widely used in Industrial, Automotive, Digital Electronics, and Semiconductor applications. Explore more semiconductor products and related Bipolar Transistors on EnvMart for enhanced electronic design and manufacturing efficiency.
