Abracon 24 MHz Crystal Unit Surface Mount 2-Pin 12.7 mm × 4.7 mm × 4.2 mm ±20 ppm Frequency Tolerance ABLS-24.000MHZ-B2-T

The Abracon ABLS-24.000MHZ-B2-T is a high-precision 24 MHz Crystal Unit designed for surface mount applications on modern compact PCBs. Featuring a low profile SMD design with two pins, it measures 12.7 mm in length, 4.7 mm in width, and 4.2 mm in height, making it suitable for space-constrained electronic assemblies.

This crystal unit delivers exceptional frequency stability with a tolerance of ±20 ppm and frequency stability of ±50 ppm, essential for demanding applications such as computers, modems, microprocessors, and wireless systems. The load capacitance of 18 pF and series resistance of 40 Ohms ensure optimal electrical performance.

Designed for rugged operating environments, the unit supports a temperature range from -20°C minimum up to 70°C maximum, broadening its usability across industrial and commercial electronics. It is RoHS compliant, guaranteeing environmentally sustainable manufacturing practices.

The product is supplied in tape and reel packaging, facilitating efficient automated pick-and-place assembly in manufacturing lines, improving production throughput. Standard frequency of 24 MHz ensures accurate oscillation.

Surface mount with 2 pins supports compact PCB designs. Dimensions are 12.7 mm length, 4.7 mm width, and 4.2 mm height. Frequency tolerance of ±20 ppm provides high precision frequency stability. Load capacitance rating is 18 pF suitable for standard circuit configurations.

Series resistance of 40 Ohms supports stable signal performance. Operating temperature range from -20°C to 70°C enables reliable use in various environments. Compliant with RoHS standards ensuring environmentally friendly material usage.

Packaged in tape and reel format for automated assembly processes.

This crystal unit is broadly applicable in industrial, laboratory, computing, telecommunications, and consumer electronics sectors where precise frequency control and reliability are critical. Abracon's ABLS series is noted for robust performance and low profile suitable for high-density PCB assemblies.
