Abracon 32MHz Crystal Oscillator Surface Mount 4-Pin HCMOS ±20 ppm FO7HHAAE20.0-T1
Specifications
| Country of Origin | India |
|---|---|
| Brand | Abracon |
| Height | 5mm |
| Length | 7mm |
| Model | FO7HHAAE20.0-T1 |
| Packaging | Tape & Reel |
| Width | 5.2mm |
| Mount Type | Surface |
| Series | FO7HH |
| Maximum Operating Temperature | 85°C |
| Output Frequency | 32MHz |
| Package Type | Surface Mount |
| Minimum Operating Temperature | -40°C |
| Standards/Approvals | RoHS |
| Pin Count | 4 |
| Maximum Supply Voltage | 5V |
| Oscillator Type | Crystal Oscillator |
| Output Level | HCMOS |
Key Features
- This crystal oscillator operates within a temperature range of -40°C to 85°C.
- It features a 4-pin surface mount package ensuring easy PCB integration.
- The oscillator requires a maximum supply voltage of 5V with 10% tolerance.
- Its frequency range covers 1 MHz to 125 MHz suitable for various electronics applications.
- Maximum soldering temperature is rated at 260°C for 10 seconds x 2, ensuring robustness during PCB assembly.
- Package type includes tape and reel packaging ideal for automated production lines.
- The oscillator is RoHS compliant and lead (Pb) free for environmental safety.
- Output disable and enable times are fast at approximately 100 ns, suitable for high-speed switching applications.
Product Description
Abracon FO7HHAAE20.0-T1 32MHz Crystal Oscillator is a high-precision, surface mount frequency source designed for demanding electronics applications. Featuring a 4-pin package type and HCMOS output level, this oscillator guarantees a frequency stability of ±20 ppm across an operating temperature range of -40°C to 85°C. Operating at a maximum supply voltage of 5V (±10%), it delivers reliable oscillation in frequency ranges from 1 MHz up to 125 MHz.
The oscillator's compact dimensions include a length of 7 mm, width of 5.2 mm, and height of 5 mm, making it ideal for modern compact PCB designs. The device comes packaged in tape and reel format, facilitating integration into automated assembly processes. The resonator employs a seam seal method and is lead-free ensuring compliance with current environmental standards.
Additional technical features include fast start-up time of 10 ms, output disable and enable times of 100 ns each, and maximum soldering temperature capability of 260°C for two 10-second intervals. This product is RoHS compliant and designed to meet industrial and commercial electronics requirements, including usage in power and control systems, communication devices, and embedded systems.
This Crystal Oscillator ensures precise frequency output with ±20 ppm stability. Its 4-pin surface mount package supports compact and lightweight PCB assembly. Wide operating temperature range accommodates harsh environmental conditions.
Fast enabling and disabling of output suit high-speed electronic circuits. Tape and reel packaging supports large-scale automated manufacturing. The device is lead-free and RoHS compliant avoiding hazardous substances. Maximum soldering temperature and duration are optimized for reliable PCB mounting.
This oscillator is ideal for industrial, laboratory, and commercial electronic applications. Explore more quality precision oscillators and clock solutions in Electronics Components at EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The output frequency of this model is 32 MHz.
It operates within a temperature range of -40°C to 85°C.
The maximum supply voltage required is 5V with a tolerance of ±10%.
The dimensions are 7 mm in length, 5.2 mm in width, and 5 mm in height.
It comes packaged in tape and reel format, which is ideal for automated production lines.
It provides an HCMOS output level.
The maximum soldering temperature is rated at 260°C for two intervals of 10 seconds each.
The startup time is approximately 10 ms.
This oscillator has a pin count of 4.
Yes, it is RoHS compliant and lead-free, ensuring environmental safety.
It is suitable for various electronics applications, including power and control systems, communication devices, and embedded systems.
The frequency stability is ±20 ppm.
