Wurth Elektronik WR-BTB Series Vertical Surface PCB Header, 64 Contact(s), 1 mm Pitch, 1 Row, Shrouded 658156303064

Wurth Elektronik 658156303064 PCB Header is a high-performance vertical surface mount connector designed for robust board-to-board connections in a variety of electronic applications. Featuring 64 contacts arranged in a single row with a precision 1 mm pitch, this PCB header provides secure electrical connections with excellent mechanical stability.

The housing is fabricated from Liquid Crystal Polymer (LCP), known for its excellent thermal stability and chemical resistance, making it ideal for demanding industrial and manufacturing environments. The brass contact pins are gold plated to ensure superior conductivity while resisting corrosion over prolonged operational periods. This connector boasts a shrouded design that protects contacts and aids in precise alignment during mating.

Engineered for currents up to 1 ampere and a voltage rating of 100 volts, the WR-BTB series PCB header supports industrial and commercial electronic products requiring reliable and compact connectors. It withstands voltages up to 250 V AC and operates effectively within temperatures ranging from -55 degrees Celsius to +85 degrees Celsius, ensuring consistent performance in diverse environmental conditions.

The solder termination type is optimized for surface mount technology (SMT), facilitating automated assembly processes. The male contacts offer compatibility with a wide range of board-to-board connector systems typically used in telecommunications, computing, automotive electronics, and instrumentation.

Manufactured in China under strict quality control, this PCB Header is a durable and precise component suitable for electronic manufacturing, laboratory equipment, and industrial automation systems.

The WR-BTB series offers reliable vertical SMT board-to-board connection. Features 64 contacts with 1 mm pitch and a single row configuration. Constructed with Liquid Crystal Polymer housing for enhanced durability. Brass contact material plated with gold ensures low resistance and corrosion protection.

Shrouded design provides protection and alignment for mating connectors. Rated for 1 A current and 100 V voltage withstanding voltage of 250 V (AC). Operational temperature range from -55°C up to 85°C. Termination type is solder suitable for surface mounting technology.

Male contact gender designed for board-to-board connector applications. Manufactured in China with a high-quality build for industrial and electronic use.
