Wurth Elektronik WR-PHD Series Straight Through Hole PCB Socket, 4-Contact, 1 Row, 2 mm Pitch, 200V, Solder 62000411821
Specifications
| Country of Origin | China |
|---|---|
| Voltage | 200V |
| Brand | Wurth Elektronik |
| Orientation | Straight |
| Current | 2A |
| Mount Type | Through Hole |
| Housing Material | Polyamide 9T |
| Contact Material | Copper Alloy |
| Series | WR-PHD |
| Durability | 500 mating cycles |
| Termination Type | Solder |
| Maximum Operating Temperature | 105°C |
| Minimum Operating Temperature | -40°C |
| Number of Rows | 1 |
| Pitch | 2mm |
| Standards/Approvals | REACh Approval Conform or declared, DIN ISO 2768, RoHS Approval, DIN EN 61760-2, UL Approval E323964 |
| Contact Plating | Gold |
| Number of Contacts | 4 |
| Contact Gender | Female |
Key Features
- Constructed with polyamide 9T housing for high durability.
- Contacts made from copper alloy with gold plating for reliable conductivity.
- Designed for through-hole mounting with solder termination.
- Operating temperature range from -40°C to +105°C.
- Compliant with RoHS, REACh, and UL standards with UL94 V-0 rated insulator flammability.
- Durability tested for 500 mating cycles ensuring stable connections.
Product Description
Wurth Elektronik 62000411821 WR-PHD Series Straight Through Hole PCB Socket is engineered for reliable electrical connections in electronic assemblies. It features 4 female contacts arranged in a single row with a 2 mm pitch, accommodating up to 200V and 2A. The housing is made from polyamide 9T (PA9T), a high-performance material offering superior durability and insulation, complemented by contacts crafted from copper alloy with gold plating for enhanced corrosion resistance and electrical performance.
This socket is designed for through-hole mounting with solder termination, ensuring secure mechanical and electrical stability on circuit boards. It operates reliably in temperatures ranging from -40°C up to +105°C, suitable for varied industrial and electronic applications including consumer electronics, industrial controls, and instrumentation.
The component complies with international standards, including RoHS, REACh, DIN ISO 2768, DIN EN 61760-2, and UL Approval E323964. Additionally, it has an insulator flammability rating of UL94 V-0, attesting to its fire safety. Durability is rated at 500 mating cycles, underlining its long service life.
Its compact 2 mm pitch and straight contact orientation make it suitable for dense PCB layouts where reliable connections and durability are critical. Typical industrial applications include electronics manufacturing, testing equipment, and embedded systems where high-reliability PCB sockets are required.
Constructed with polyamide 9T housing for high durability. Contacts made from copper alloy with gold plating for reliable conductivity. Designed for through-hole mounting with solder termination. Operating temperature range from -40°C to +105°C.
Compliant with RoHS, REACh, and UL standards with UL94 V-0 rated insulator flammability. Durability tested for 500 mating cycles ensuring stable connections. Explore more products in the PCB Sockets category for enhanced connectivity solutions in your electronic projects.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum voltage rating for this PCB socket is 200V.
This socket has a current capacity of 2A.
The housing is made from polyamide 9T, while the contacts are crafted from copper alloy with gold plating.
The operating temperature range for this model is from -40°C to +105°C.
This socket features 4 female contacts arranged in a single row.
It is designed for through-hole mounting with solder termination.
The durability rating is tested for 500 mating cycles.
This socket complies with RoHS, REACh, DIN ISO 2768, DIN EN 61760-2, and has UL Approval E323964.
The pitch size of the contacts in this socket is 2 mm.
The contacts in this model have a straight orientation.
The country of origin for this PCB socket is China.
This socket is suitable for various applications including consumer electronics, industrial controls, and instrumentation.
