Wurth Elektronik WR-PHD Series Straight Through Hole PCB Socket, 4-Contact, 2 Row, 2 mm Pitch, 2A Current, 200V 62000421821
Specifications
| Country of Origin | China |
|---|---|
| Voltage | 200V |
| Brand | Wurth Elektronik |
| Orientation | Straight |
| Current | 2A |
| Mount Type | Through Hole |
| Housing Material | Polyamide 9T |
| Contact Material | Copper Alloy |
| Series | WR-PHD |
| Durability | 25 mating cycles |
| Termination Type | Solder |
| Maximum Operating Temperature | 105°C |
| Minimum Operating Temperature | -40°C |
| Number of Rows | 2 |
| Pitch | 2mm |
| Standards/Approvals | REACh Approval Conform or declared, DIN ISO 2768, DIN EN 61760-2, UL Approval E323964, RoHS Approval |
| Contact Plating | Gold |
| Number of Contacts | 4 |
| Contact Gender | Female |
Key Features
- Supports current up to 2A and voltage rating of 200V.
- Constructed with durable polyamide 9T housing material.
- Features copper alloy female contacts with gold plating for reliable connectivity.
- Designed for through hole mounting with a straight orientation.
- Operates within a temperature range from -40°C to 105°C.
- Insulator material rated UL94 V-0 for flammability resistance.
- Durability rating of 25 mating cycles ensures longevity.
- Complies with REACh, RoHS, UL and DIN standards.
Product Description
Wurth Elektronik's WR-PHD Series PCB socket model 62000421821 is a straight through hole connector designed for circuit board applications requiring secure and reliable electrical connections. This socket features 4 female contacts arranged in 2 rows at a 2 mm pitch, specifically designed to handle 2A current and withstand voltages up to 200V.
The housing is manufactured from polyamide 9T (PA9T), which offers excellent mechanical strength and thermal stability. The contact material is copper alloy with gold plating ensuring low contact resistance and corrosion resistance. The socket supports through hole mounting and is oriented straight, simplifying conventional PCB assembly processes.
It is suitable for applications requiring operation in temperatures ranging from -40°C low to 105°C high. The UL94 V-0 flammability rating of the insulator material guarantees safety under thermal stress.
This component is UL approved (E323964), RoHS compliant, and meets DIN ISO 2768 and DIN EN 61760-2 standards, reflecting high quality and environmental compliance. With a durability of 25 mating cycles, it is reliable for repeated use during assembly and maintenance.
Common usage scenarios include industrial electronics, communications equipment, instrumentation, and other electrical component assemblies where robust PCB connections are required.
Supports current capacity of 2A and voltage rating of 200V. Manufactured with polyamide 9T housing and copper alloy contacts with gold plating. Ensures safety with UL94 V-0 insulator rating and UL approval E323964. Complies with REACh and RoHS directives and DIN standards.
Durability of 25 mating cycles for secure, lasting connections. Explore more PCB socket and connector solutions within the Electronics Components category at EnvMart for your design and manufacturing needs.
Explore more products in our PCB Sockets category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model supports a maximum current of 2A and a voltage rating of 200V.
It features a housing made of polyamide 9T and female contacts made from copper alloy with gold plating.
The socket has a pitch of 2mm and is configured with 4 female contacts arranged in 2 rows.
This model has a durability rating of 25 mating cycles, ensuring reliable connections over repeated use.
It operates within a temperature range from -40°C to 105°C.
This socket is designed for through hole mounting, facilitating conventional PCB assembly processes.
It complies with REACh, RoHS directives, and meets DIN ISO 2768, DIN EN 61760-2 standards, and has UL approval (E323964).
The contacts are oriented straight, which simplifies the assembly process on PCBs.
This model uses solder as the termination type for secure electrical connections.
It is suitable for applications in industrial electronics, communications equipment, instrumentation, and other electrical component assemblies.
The insulator material is rated UL94 V-0 for flammability resistance, ensuring safety under thermal stress.
The country of origin for this model is China.
