Samtec MPS Series Vertical Through Hole PCB Socket 3-Contact 1 Row 5 mm Pitch Solder MPS-03-7.70-01-L-V

Name: Samtec MPS Series Vertical Through Hole PCB Socket 3-Contact 1 Row 5 mm Pitch Solder MPS-03-7.70-01-L-V
Brand: Samtec
SKU: 111972
Price: 5.99 USD
Availability: InStock



Category PCB Sockets Brand Samtec Condition New

Specifications

Country of Origin	India
Voltage	848V
Brand	Samtec
Orientation	Vertical
Current	41.7A
Model	MPS-03-7.70-01-L-V
Mount Type	Through Hole
Housing Material	Liquid Crystal Polymer
Contact Material	Copper
Series	MPS
Termination Type	Solder
Maximum Operating Temperature	125°C
Sub Type	Socket
Minimum Operating Temperature	-55°C
Number of Rows	1
Pitch	5mm
Standards/Approvals	RoHS
Contact Plating	Gold
Number of Contacts	3
Contact Gender	Female
Connector System	Board-to-Board
Stacking Height	14mm
Row Pitch	2.54mm

Key Features

Constructed with liquid crystal polymer housing for durability.
Supports current up to 41.7 A ensuring high power capability.
Gold-plated copper contacts provide excellent conductivity.
Stacking height of 14 mm, suitable for compact PCB layouts.
Vertical orientation and through-hole mount design for reliable soldering.
Operates reliably between -55°C and 125°C temperature range.
Compliance with RoHS standards ensures environmental safety.
Single row with 3 female contacts and 2.54 mm row pitch offers precise connector alignment.

Product Description

Samtec MPS-03-7.70-01-L-V is a high-quality vertical through-hole PCB socket designed for board-to-board connections. It features a robust liquid crystal polymer housing and gold-plated copper contacts ensuring durability and excellent electrical conductivity.

This 3-contact, single-row socket has a 5 mm pitch and supports a current rating of 41.7 A, suitable for high-power electronic applications. The socket's 14 mm stacking height and vertical orientation make it ideal for compact and efficient PCB designs.

Rated for voltages up to 848 V, this component operates reliably within a wide temperature range from -55°C to 125°C, accommodating demanding industrial environments. Its termination type is solder, facilitated by through-hole mounting for secure connections.

Designed to comply with RoHS standards, the MPS Series socket ensures safe, environmentally friendly electronic assembly. The 2.54 mm row pitch and female contact gender provide precise mating and reliable performance in various electronic and manufacturing uses.

Constructed with liquid crystal polymer housing for durability. Supports current up to 41.7 A ensuring high power capability. Gold-plated copper contacts provide excellent conductivity. Stacking height of 14 mm, suitable for compact PCB layouts.

Vertical orientation and through-hole mount design for reliable soldering. Rated voltage of 848 V for demanding electronic applications. Operates reliably between -55°C and 125°C temperature range. Compliance with RoHS standards ensures environmental safety.

Single row with 3 female contacts and 2.54 mm row pitch offers precise connector alignment. Ideal for industrial, electronic assembly, manufacturing, and laboratory use cases.

This PCB socket is widely used in electronic manufacturing, industrial control systems, and laboratory equipment, where reliable and stable connections are critical. Suitable for professional PCB assembly, it enhances performance and longevity of devices.
