Epson 25 MHz Surface Mount Crystal Unit FA-238 4-Pin ±50 ppm Frequency Tolerance Q22FA2380014312
Specifications
| Country of Origin | India |
|---|---|
| Frequency range | 16 MHz to 60 MHz |
| Brand | Epson |
| Height | 0.7mm |
| Length | 3.2mm |
| Model | Q22FA2380014312 |
| Width | 2.5mm |
| Mount Type | Surface |
| Series | FA-238 |
| Maximum Operating Temperature | 85°C |
| Package Type | FA-238 |
| Minimum Operating Temperature | -40°C |
| Interfaces | LAN ISM band radio, Clock for MPU |
| External Dimensions | 3.2 x 2.5 x 0.7 mm |
| Standards/Approvals | RoHS, REACH |
| Pin Count | 4 |
| Standard Frequency | 25MHz |
| Load Capacitance | 18pF |
| Series Resistance | 60Ω |
| Overtone order | Fundamental |
Key Features
- Compact FA-238 package measuring 3.2mm x 2.5mm x 0.7mm.
- Operates within a temperature range of -40°C to 85°C.
- Load capacitance of 18 pF ensures stable oscillation.
- Series resistance is 60 ohms for optimal performance.
- Designed for fundamental overtone operation in mobile phones and Bluetooth applications.
- Four-pin configuration enables secure surface mount installation.
- Complies with RoHS and REACH standards for environmental safety.
Product Description
The Epson Q22FA2380014312 is a 25 MHz Surface Mount Crystal Unit designed for high-stability frequency generation in electronic circuits. Packaged in the low-profile FA-238 case, it provides precise frequency tolerance of ±50 ppm, making it suitable for demanding applications such as mobile phones, Bluetooth communication devices, WLAN ISM band radios, and MPU clock references.
Measuring a compact 3.2 mm in length, 2.5 mm in width, and 0.7 mm in height, this miniature crystal unit is ideal for space-constrained surface mount technology (SMT) designs. Operating temperature ranges from -40°C to 85°C, ensuring reliability in various industrial and commercial environments.
Featuring a load capacitance of 18 pF and a series resistance of 60 ohms, the unit supports stable oscillation at its fundamental overtone. The 4-pin configuration facilitates easy integration onto printed circuit boards, meeting RoHS and REACH environmental compliance requirements.
This crystal unit is part of Epson's FA-238 series, which offers frequency ranges from 16 MHz to 60 MHz to meet different application needs. Its robust design supports usage in electronics manufacturing, communication equipment, and embedded systems.
Compact surface mount FA-238 package. Frequency tolerance within ±50 ppm for precise timing. Wide operating temperature range from -40°C to 85°C. Fundamental overtone operation with low series resistance. 4-pin configuration for reliable PCB mounting.
RoHS and REACH compliant for environmental safety.
Ideal for industrial, telecommunications, consumer electronics, and embedded computer applications. Browse EnvMart for more Crystal Units and surface mount components to optimize your designs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The frequency tolerance of the Epson Q22FA2380014312 is ±50 ppm, ensuring precise timing for various applications.
This model operates within a temperature range of -40°C to 85°C, making it suitable for diverse industrial and commercial environments.
The FA-238 package measures 3.2 mm in length, 2.5 mm in width, and 0.7 mm in height, making it compact for surface mount applications.
The load capacitance of this crystal unit is 18 pF, which supports stable oscillation at its fundamental overtone.
The series resistance of this crystal unit is 60 ohms, optimizing its performance for frequency generation.
This crystal unit is designed for applications in mobile phones, Bluetooth communication devices, WLAN ISM band radios, and MPU clock references.
The Epson Q22FA2380014312 features a 4-pin configuration, facilitating secure surface mount installation.
This unit complies with RoHS and REACH standards, ensuring environmental safety in its manufacturing.
The overtone order of this model is fundamental, which is typical for applications requiring stable frequency generation.
This model supports surface mounting, making it suitable for compact electronic designs.
The FA-238 series offers a frequency range from 16 MHz to 60 MHz, accommodating various application needs.
The country of origin for this crystal unit is India, reflecting its manufacturing location.
