Samtec High Reliability PCB Socket 50-Contact, 2 Row, 1.27 mm Pitch, 3.2 A Current, Surface Mount SFM-125-01-S-D

Samtec SFM-125-01-S-D is a high reliability, straight surface PCB socket designed specifically for rigorous electronic component interconnections. It features a dual-row configuration with 50 female contacts spaced on a 1.27 mm pitch to accommodate dense PCB layouts. The contacts are made from beryllium copper alloy with a 0.25 μm gold plating to guarantee excellent electrical performance and durability.

The housing is made of liquid crystal polymer, offering superior heat resistance and mechanical strength, making this socket suitable for demanding industrial, laboratory, manufacturing, and electronics assembly applications. It supports a rated current of 3.2 A per pin and can operate reliably across a wide temperature range from -55°C to 125°C, ensuring longevity even in harsh conditions.

This PCB socket is intended for surface mount installation with a stacking height of 12 mm, enabling high-density stacking and compact circuit assemblies. It is designed for board-to-board and cable connector systems requiring secure and high-performance electrical connections.

Key features include a voltage rating of 250 VAC, gold-plated contacts to minimize corrosion and contact resistance, and a straight mount orientation for easy PCB integration. The component is ideal for electronic equipment requiring stable and reliable socket connections adhering to high reliability standards.

Features 50 precision beryllium copper alloy contacts plated with gold for enhanced conductivity. Dual row configuration with 1.27 mm pitch ensures reliable board-to-board or cable connection. Supports a current of up to 3.2 amperes per contact.

Constructed with liquid crystal polymer housing material for thermal and mechanical stability. Surface mounting with straight orientation and stacking height of 12 mm for compact PCB layouts. Voltage rating up to 250 volts AC for versatile electronic applications.

Operates in temperature range of -55°C to 125°C for industrial and harsh environment use. Connector compatible with board-to-board and cable systems requiring high reliability.
