Samtec TSW Series Straight Through Hole Pin Header 8 Contacts 2.54 mm Pitch 2 Row Unshrouded TSW-104-17-G-D
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 550V |
| Brand | Samtec |
| Orientation | Straight |
| Model | TSW-104-17-G-D |
| Mount Type | Through Hole |
| Special Features | Many options fo |
| Housing Material | Glass Filled Polyester |
| Contact Material | Phosphor Bronze |
| Series | TSW |
| Termination | Through-hole |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 2 |
| Pitch | 2.54mm |
| Contact Plating | Gold |
| Number of Contacts | 8 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Unshrouded |
| Connector System | Board-to-Board |
| Contact System | .025" (0.635 mm) square post |
Key Features
- Constructed from glass filled polyester housing for durability.
- Features gold-plated phosphor bronze contacts for reliable conductivity.
- Unshrouded design enables easy board-to-board connection.
- Operates across a wide temperature range from -55°C to 125°C.
- Supports voltage rating up to 550V for robust electrical performance.
- Termination type is solder, suitable for through-hole PCB mounting.
- Contact system employs a 0.025 inch (0.635 mm) square post for secure fit.
- Designed as male contacts in a 2-row configuration.
Product Description
Samtec TSW-104-17-G-D is a high-quality pin header from the TSW series, designed for straight through hole PCB mounting with 8 contacts arranged in 2 rows. This connector features a robust glass filled polyester housing and gold-plated phosphor bronze contacts to ensure reliable electrical connections and resistance to corrosion.
The header has a 2.54 mm pitch and uses a 0.025 inch (0.635 mm) square post contact system. Its unshrouded configuration facilitates easy board-to-board connections in electronic assemblies.
Operating over a temperature range of -55°C to 125°C and supporting voltages up to 550V, this pin header suits a wide variety of industrial, manufacturing, and electronic applications. The solder termination type provides secure and stable mounting on printed circuit boards.
The product is designed to meet industry needs for consistent pin counts, terminal lengths, and configurations, ideal for use in power connectors, PCB connectors, and electronic component assemblies. Its features include male contact gender and a vertical, straight orientation suitable for compact PCB layouts.
Constructed from glass filled polyester housing for durability and thermal stability. Gold plating on phosphor bronze contacts ensures high conductivity and corrosion resistance. Unshrouded design allows easy access for system integration.
Wide operating temperature and voltage specifications support diverse applications. Through hole mount with solder termination provides reliable mechanical and electrical connection.
This Samtec TSW series pin header is widely applicable in electronic manufacturing, industrial automation, and electrical connector assembly. Its proven performance and standardized dimensions make it a dependable choice for PCB interconnections and power delivery systems.
Discover more from the Electronics & Electricals category for high-quality PCB connectors and electronic components at EnvMart.
Explore more products in our PCB Pin Header category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The pitch of this pin header is 2.54 mm.
It supports a maximum voltage rating of 550V.
The housing is made from glass filled polyester, and the contacts are made of phosphor bronze with gold plating.
It operates within a temperature range of -55°C to 125°C.
This pin header has 8 contacts arranged in 2 rows.
It uses a solder termination type suitable for through-hole mounting.
The contact system employs a 0.025 inch (0.635 mm) square post for a secure fit.
This model features an unshrouded design, allowing for easy board-to-board connections.
The orientation of this pin header is straight.
It is manufactured in India.
It supports a board-to-board connector system.
The contacts are designed as male.
