Samtec SMH Series Straight Surface Mount PCB Socket 20-Contact 1 Row 2.54 mm Pitch SMH-120-02-L-S
Specifications
| Country of Origin | India |
|---|---|
| Brand | Samtec |
| Orientation | Straight |
| Model | SMH-120-02-L-S |
| Mount Type | Surface |
| Housing Material | Liquid Crystal Polymer |
| Contact Material | Phosphor Bronze |
| Series | SMH |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Sub Type | Surface Mount Socket Strip |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 1 |
| Pitch | 2.54mm |
| Standards/Approvals | RoHS |
| Contact Plating | Gold |
| Number of Contacts | 20 |
| Contact Gender | Female |
| Connector System | Board-to-Board |
Key Features
- The socket features 20 female contacts arranged in a single row.
- Constructed with a Liquid Crystal Polymer housing ensuring durability and stability.
- Contact material is phosphor bronze plated with gold for superior conductivity and corrosion resistance.
- Designed to operate reliably between -55°C and 125°C temperature range.
- Mount type is surface mount with a straight orientation aiding easy PCB integration.
- Part of the SMH series, known for precise 2.54 mm pitch spacing.
- RoHS compliant, ensuring adherence to environmental standards.
- Ideal for industrial and electronic PCB assembly applications.
Product Description
Samtec SMH-120-02-L-S PCB Socket is a 20-contact, single row surface mount socket designed for board-to-board connection systems. It features a standard 2.54 mm pitch with a straight orientation and solder termination type, making it well-suited for industrial electronics and PCB assembly environments.
The socket's housing is made from Liquid Crystal Polymer (LCP), known for its mechanical strength and high thermal stability. The electrical contacts are crafted from phosphor bronze and plated with gold, providing exceptional conductivity and resistance to oxidation. The contact gender is female, fitting compatible male pins.
This product operates reliably within a wide temperature range from -55°C to 125°C, accommodating diverse environmental conditions encountered in manufacturing, automation, and electronic devices.
As part of the SMH series, this connector maintains consistent quality and precise pin pitch of 2.54 mm, ensuring compatibility with standard PCB layouts. The socket is surface-mounted on PCBs, facilitating ease of installation in automated manufacturing processes.
Being RoHS compliant, the product confirms adherence to European environmental directives, ensuring less hazardous material content. The socket features 20 female contacts arranged in a single row. Constructed with a Liquid Crystal Polymer housing ensuring durability and stability.
Contact material is phosphor bronze plated with gold for superior conductivity and corrosion resistance. Designed to operate reliably between -55°C and 125°C temperature range. Mount type is surface mount with a straight orientation aiding easy PCB integration.
Part of the SMH series, known for precise 2.54 mm pitch spacing. RoHS compliant, ensuring adherence to environmental standards. Ideal for industrial and electronic PCB assembly applications.
This Samtec SMH series PCB socket is widely used in electronics manufacturing industries, industrial automation, and other high-reliability applications requiring secure and durable PCB interconnections. Its design supports efficient soldering processes and long-term performance.
Explore the Electronics & Electricals category at EnvMart for a comprehensive range of PCB connectors and related components to suit your industrial and manufacturing needs.
Explore more products in our PCB Sockets category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The contacts in this PCB socket have a pitch of 2.54 mm, which is standard for many PCB layouts.
This model can operate reliably at a maximum temperature of 125°C.
The socket features 20 female contacts arranged in a single row.
The housing is made from Liquid Crystal Polymer, and the contacts are made of phosphor bronze plated with gold for conductivity and corrosion resistance.
Yes, the SMH-120-02-L-S is RoHS compliant, adhering to environmental standards regarding hazardous materials.
This model utilizes a solder termination type, suitable for surface mount applications.
The socket features a straight orientation, which aids in easy PCB integration.
The minimum operating temperature for this PCB socket is -55°C.
This socket is designed for board-to-board connection systems.
The country of origin for this product is India.
The socket has female contacts, which are designed to fit compatible male pins in board-to-board connections.
This socket is ideal for industrial electronics and PCB assembly applications, particularly in manufacturing and automation environments.
