| Country of Origin | India |
|---|---|
| Brand | DiodesZetex |
| Height | 1.1mm |
| Length | 3mm |
| Model | DZ23C15-7-F |
| Mount Type | Surface |
| Series | DZ23C15 |
| Maximum Operating Temperature | 150°C |
| Package Type | SOT-23 |
| Minimum Operating Temperature | -65°C |
| Pin Count | 3 |
| Number of Elements per Chip | 2 |
| Automotive Standard | AEC-Q101 |
| Maximum Power Dissipation Pd | 300mW |
| Diode Configuration | Common Cathode |
| Test Current It | 5mA |
| Maximum Reverse Leakage Current | 100nA |
| Nominal Zener Voltage Vz | 15V |
| Zener Type | General Purpose |
| Maximum Zener Impedance | 30Ω |
DiodesZetex DZ23C15-7-F is a 2, 15 V Zener Diode featuring a common cathode configuration designed for surface mount mounting in a compact 3-pin SOT-23 package. It offers a maximum power dissipation of 300 mW and a Zener voltage tolerance of ±6%, making it suitable for precision voltage regulation and protection circuits in electronics.
This diode exhibits a low maximum reverse leakage current of 100 nA and a maximum Zener impedance of 30 Ω, contributing to enhanced efficiency and reduced power loss in sensitive circuits. It is capable of operating over a wide temperature range from -65°C up to 150°C, further supported by automotive standard AEC-Q101 certification, ensuring reliability in demanding automotive and industrial environments.
The device includes two elements per chip, providing common cathode configuration, facilitating implementation in voltage stabilization applications. Its small size with a 3 mm length and 1.1 mm height in the SOT-23 package enables compact PCB layout designs.
Maximum power dissipation of 300 mW for effective thermal management. Nominal Zener voltage of 15 V with 6% tolerance for precise voltage regulation. Surface mount 3-pin SOT-23 package for space-saving installation. Low maximum reverse leakage current of 100 nA reduces circuit losses.
Wide operating temperature range from -65°C to 150°C. General purpose Zener diode suitable for various electronic applications. Automotive standard AEC-Q101 ensures high reliability in automotive systems. Typical voltage temperature coefficient of 0.08%/°C stabilizes voltage across temperatures.
Test current of 5 mA applied for performance verification.
This Zener Diode is ideal for use in industrial electronics, automotive circuits, power supply regulation, and protection applications where stable voltage reference and low power loss are critical factors.
Explore the Electronics & Electricals category for more semiconductor and diode components at EnvMart.
