onsemi Zener Diode 15 V 500 mW Surface Mount 2-Pin SOD-523 MM5Z15VT1G

Free Delivery in India | Lowest Global Shipping Charges

onsemi Zener Diode 15 V 500 mW Surface Mount 2-Pin SOD-523 MM5Z15VT1G

Name: onsemi Zener Diode 15 V 500 mW Surface Mount 2-Pin SOD-523 MM5Z15VT1G
Brand: onsemi
SKU: 106729
Price: 0.04 USD
Availability: InStock



Category Zener Diodes Brand onsemi Condition New

Specifications

Country of Origin	India
Brand	onsemi
Height	0.7mm
Length	1.7mm
Model	MM5Z15VT1G
Mount Type	Surface
Series	MM5ZxxxT1G
Maximum Operating Temperature	150°C
Package Type	SOD-523
Minimum Operating Temperature	-65°C
Pin Count	2
Number of Elements per Chip	1
Maximum Power Dissipation Pd	500mW
Diode Configuration	Single
Test Current It	5mA
Maximum Reverse Leakage Current	50nA
Nominal Zener Voltage Vz	15V
Zener Type	Voltage Regulator
Maximum Zener Impedance	30Ω
Typical Voltage Temperature Coefficient	13mV/K
Surface Mount case	SOD-523

Key Features

This Zener diode features a nominal voltage of 15 V with ±5% tolerance.
Maximum power dissipation rating is 500 mW ensuring stable performance.
Surface mount package type SOD-523 with compact dimensions of 1.7 mm length and 0.7 mm height.
Maximum reverse leakage current is 50 nA supporting low leakage in circuits.
Test current for the diode is 5 mA with maximum Zener impedance of 30 Ω.
Operating temperature ranges from -65°C to 150°C for reliable usage.
Designed as a voltage regulator with 2-pin configuration for PCB mounting.
Typical voltage temperature coefficient is 13 mV/K assuring voltage stability over temperature.

Product Description

onsemi MM5Z15VT1G is a high-quality Zener diode designed for voltage regulation in electronic circuits, featuring a nominal zener voltage of 15 V and maximum power dissipation of 500 mW.

This diode is configured as a single element per chip with a surface mount type package, the compact SOD-523 case, measuring 1.7 mm in length and 0.7 mm in height, suitable for space-constrained PCB designs.

The device offers excellent performance characteristics including a maximum reverse leakage current of 50 nA, maximum Zener impedance of 30 Ω, and a test current of 5 mA, ensuring precision voltage regulation and efficient power handling.

It operates reliably across a wide temperature range from -65°C to 150°C, making it suitable for various industrial and commercial electronic applications.

This Zener diode is a voltage regulator type with 2 pins optimized for surface-mount technology, offering ease of assembly and robust electrical characteristics for semiconductors requiring stable voltage references.

This Zener diode features a nominal voltage of 15 V with ±5% tolerance. Maximum power dissipation rating is 500 mW ensuring stable performance. Surface mount package type SOD-523 with compact dimensions of 1.7 mm length and 0.7 mm height.

Maximum reverse leakage current is 50 nA supporting low leakage in circuits. Test current for the diode is 5 mA with maximum Zener impedance of 30 Ω. Operating temperature ranges from -65°C to 150°C for reliable usage. Designed as a voltage regulator with 2-pin configuration for PCB mounting.

Typical voltage temperature coefficient is 13 mV/K assuring voltage stability over temperature. This product is widely used in industrial electronics, power supply designs, instrumentation, and automotive circuits where precise voltage regulation is critical.

Explore a range of semiconductor components including diodes and voltage regulators with onsemi products available at EnvMart for your electronic development needs.
