Samtec High Reliability Straight Surface PCB Socket 50-Contact, 2 Row, 1.27 mm Pitch, 3.2A, 250V SFM-125-02-S-D

Samtec SFM-125-02-S-D is a high reliability straight surface PCB socket designed for electronics applications requiring robust and precise connections. It features 50 contacts arranged in 2 rows with a pitch of 1.27 mm, providing a compact and efficient interface for PCB mounting. Operating at voltages up to 250 V and currents of 3.2 A per pin (with 2 pins powered), this socket supports demanding electrical requirements.

The socket's contacts are made of beryllium copper alloy and plated with gold, ensuring excellent conductivity and resistance to corrosion. The black liquid crystal polymer housing provides mechanical strength and high-temperature performance with an operating range from -55°C to 125°C. Mount type is surface mount with a stacking height of 12 mm, suitable for space-optimized PCB designs.

This PCB socket supports cable and board-to-board connector systems, featuring female contact gender and a straight orientation for easy integration. The termination type is solder, offering reliable mechanical and electrical connections in printed circuit boards.

This component is ideal for use in industrial electronics, telecommunications, computing hardware, and other electronic assemblies requiring durable and high-performance PCB socket connectors. The Samtec SFM series ensures high reliability in complex electronic systems and supports RoHS compliance.

This PCB socket features a 1.27 mm pitch for precise board connection. It accommodates 50 contacts arranged in 2 rows for high-density applications. The contact material is beryllium copper alloy with gold plating for durability and conductivity.

Designed for surface mounting with a stacking height of 12 mm. Suitable for operating temperatures ranging from -55°C to 125°C. Rated for 250 V voltage and current up to 3.2 A per pin with 2 pins powered. The housing is made from black liquid crystal polymer for mechanical robustness.

Connector system supports cable, board-to-board configurations with female contact gender. Termination type is solder, ensuring secure and reliable connections. The orientation is straight to facilitate straightforward PCB layout integration.
