Samtec CES Series Vertical Through Hole PCB Socket 9-Contact 1 Row 2.54 mm Pitch Solder CES-109-01-T-S

The Samtec CES-109-01-T-S is a vertical through hole PCB socket designed for reliable board-to-board electrical connections. Featuring 9 contacts arranged in a single row with a 2.54 mm pitch, this socket belongs to the CES series known for its low profile and high durability. The housing is constructed from black glass filled polyester, providing robust insulation and mechanical strength suitable for industrial and commercial electronic applications.

The contacts are made of phosphor bronze with tin plating, ensuring excellent conductivity and corrosion resistance. It supports an electrical rating of 400V and a current of 5.5A per pin, making it suitable for a wide range of electronic equipment and PCB assemblies where reliable current handling is essential.

This PCB socket is designed for through-hole mounting and vertical orientation, simplifying integration into printed circuit boards. Its operating temperature range from -55°C to 105°C allows usage in diverse environments, including industrial, manufacturing, and laboratory settings.

The dual leaf contact system enhances connection stability and electrical performance, minimizing insertion force while maintaining secure contacts. This socket's board-to-board connector system and single-row configuration suit compact and precision-demanding electronic designs.

Termination is solder-based, ensuring durable mechanical and electrical bonds during manufacturing and assembly. The product complies with RoHS standards, confirming that it meets contemporary regulations for hazardous substances in electronic components.

The socket features a black glass filled polyester housing for material durability. Contacts of phosphor bronze with tin plating provide reliable electrical performance. Rated for 400V voltage and 5.5A current per contact.

Designed for through-hole vertical mounting on PCBs. Operating temperature range from -55°C to 105°C. CES series low profile design with dual leaf contact system. Board-to-board connector system with 9 contacts in 1 row.

Solder termination type ensures secure attachment. RoHS compliant for environmental safety.

This Samtec PCB socket is ideal for applications in electronic assembly, industrial equipment, telecommunications, and other environments requiring robust and precise board connections. For more options, explore the PCB Socket category at EnvMart to find compatible connectors and accessories.
