KEMET Film Capacitor 2.7 nF ±5 % 1 kV DC 600 V AC Through Hole R76QF127050H0J

Name: KEMET Film Capacitor 2.7 nF ±5 % 1 kV DC 600 V AC Through Hole R76QF127050H0J
Brand: KEMET
SKU: 103869
Price: 0.27 USD
Availability: InStock



Category Film Capacitor Brand KEMET Condition New

Specifications

Country of Origin	China
Capacitance Range	100 pF - 15 μF
Brand	KEMET
Height	9mm
Length	13mm
Model	R76QF127050H0J
Packaging	Bag
Width	4mm
Mount Type	Through Hole
Series	R76_125C
Maximum Operating Temperature	125°C
Tolerance	±5 %
Capacitance	2.7nF
Minimum Operating Temperature	-55°C
Terminal type	Solder
Dissipation Factor	0.1%
Lead Length	25mm
Standards/Approvals	IEC 60286-2, RoHS
Pin Count	2
Rated AC Voltage	600V ac
Rated DC Voltage	1kV dc
Lead Pitch	10mm
Lead Diameter	0.6mm
Automotive Standard	AEC-Q200
Capacitance tolerance	±2.5%, ±5%, ±10%
Lead Spacing	10 mm - 37.5 mm
Equivalent Series Resistance ESR	236mΩ

Key Features

This capacitor supports a rated AC voltage of 600 V and operates from -55°C to 125°C.
It features a through-hole mount type ideal for secure PCB mounting.
The component has a lead pitch of 10 mm and comes packaged in a bag.
The series R76_125C uses polypropylene film and double metallized polyester film electrodes.
It boasts an equivalent series resistance (ESR) of 236 mΩ and a dissipation factor of 0.1%.
Compliant with automotive standard AEC-Q200 and IEC 60286-2, suitable for harsh environments.
Typical applications include resonant circuits, high frequency and high current, snubber circuits, and semiconductor commutation circuits.

Product Description

KEMET R76QF127050H0J Film Capacitor is a high-quality component designed with ±5 % tolerance capacitance of 2.7 nF and operating voltage of 1 kV DC and 600 V AC. It features a through-hole mounting style with radial leads spaced at 10 mm pitch, making it suitable for robust PCB assembly in electronic applications.

Constructed with polypropylene film and double metallized polyester film electrodes, this capacitor provides excellent performance with an ESR of 236 mΩ and low dissipation factor of 0.1%, ensuring efficiency in demanding electrical circuits. The capacitor is housed in a self-extinguishing, solvent-resistant plastic case with thermosetting resin for enhanced durability and safety.

The product meets automotive standard AEC-Q200 and IEC 60286-2 certifications, ensuring reliability in automotive and industrial applications. Operating temperature ranges from -55°C to 125°C, the capacitor is suitable for harsh environments and high frequency uses.

Its primary applications include resonant circuits, high-frequency high-current snubber circuits, and silicon-controlled rectifier (SCR), IGBT, and SiC MOSFET commutation circuits. The capacitor's electrical properties support usage in circuits requiring high voltage, current, and temperature tolerance, commonly found in industrial, laboratory, and automotive electronic assemblies.

Packaging is provided in a convenient bag format for bulk usage. Lead dimensions include a 25 mm length and 0.6 mm diameter, allowing ease of soldering and mounting on PCBs. This capacitor features 2.7 nF capacitance with tight ±5% tolerance.

Rated to operate at 1 kV DC and 600 V AC voltage. Through-hole mounted with 10 mm lead pitch and solder terminals. Complies with automotive standards and IEC approvals for demanding use cases. Operates reliably between -55°C and +125°C temperature range.

Constructed with polypropylene and metallized polyester film for durability and performance. Typical applications include high-frequency, high-current, and snubber circuits. Explore more Film Capacitors and electronic components for your industrial, automotive, laboratory, and manufacturing needs on EnvMart.
