KEMET Film Capacitor 10 nF ±5% 1.6 kV DC 650 V AC Through Hole Mount R76TI210050H4J

The KEMET R76TI210050H4J film capacitor is designed for efficient electrical performance in demanding environments, rated at 10 nF capacitance with ±5 % tolerance. It supports high voltage applications up to 1.6 kV DC and 650 V AC, making it suitable for power electronics and industrial circuits.

Constructed from polypropylene film and double metallized polyester film electrodes, the capacitor offers excellent stability and low losses. The radial leads are welded to the capacitor winding and encapsulated in a self-extinguishing, solvent-resistant plastic case with thermosetting resin, ensuring durability and safety.

The capacitor features a through hole mount with a 15 mm lead pitch and solder terminal type for secure installation. It operates reliably within a temperature range of -55°C to 125°C, supporting harsh environment conditions. Its compact size (18 mm length, 5 mm width, 11 mm height) allows for efficient PCB layout.

Performance characteristics include a low dissipation factor of 0.1 %, an equivalent series resistance (ESR) of 64 mΩ, and leads with 25 mm length and 0.8 mm diameter, optimized for electronic assembly. The product complies with RoHS, IEC 60286-2 standards and holds the automotive AEC-Q200 standard, confirming quality and durability for automotive electronics usage.

This film capacitor is ideal for resonant circuits, high-frequency, high-current applications such as snubbers, silicon-controlled rectifiers (SCR), IGBT circuits, and SiC MOSFET commutation circuits. The capacitor is well-suited for applications requiring high voltage, high current, and high ambient temperatures.

Its tape and reel packaging facilitates automated assembly processes. Manufactured in China, the capacitor aligns with industry requirements for reliability and performance in demanding industrial, automotive, and electronics manufacturing environments.

Explore the comprehensive selection of Film Capacitors at EnvMart for reliable components designed for advanced electronic applications. Constructed with polypropylene and double metallized polyester film electrodes. Suitable for high frequency, high current, and snubber applications.

Operating temperature range from -55°C to 125°C. Radial leads with 15 mm lead pitch and solder terminal type. Meets RoHS and IEC 60286-2 standards with automotive standard AEC-Q200 certification. Compact dimensions: 18 mm length, 5 mm width, 11 mm height.

Low equivalent series resistance of 64 mΩ for stable performance. Lead length of 25 mm and 0.8 mm lead diameter ensuring reliable connections.
