Maxim Integrated 8-Channel 12-Bit SAR ADC 100 ksps, 28-Pin SOIC MAX197BEWI+
Specifications
| Country of Origin | India |
|---|---|
| Resolution | 12 bit |
| Brand | Maxim Integrated |
| Height | 2.64mm |
| Length | 18.08mm |
| Model | MAX197BEWI+ |
| Mount Type | Surface |
| Sampling rate | 100ksps |
| Series | MAX197 |
| Input Type | Single Ended |
| Maximum Operating Temperature | 85°C |
| Package Type | SOIC |
| Minimum Operating Temperature | -40°C |
| Interface Type | Parallel |
| Architecture | SAR |
| Pin Count | 28 |
| Maximum Supply Voltage | 5V |
| Minimum Supply Voltage | 4.75V |
| Number of ADCs | 8 |
| Software-Selectable Input Ranges | ±10V, ±5V, 0V to 10V, 0V to 5V |
Key Features
- High resolution 12-bit successive approximation register architecture for accurate conversion.
- Supports 8 analog input channels with fault-protected multiplexer handling ±16.5V inputs.
- Software selectable input voltage ranges including ±10V, ±5V, 0 to 10V, and 0 to 5V.
- Operates with single +5V supply voltage with minimum 4.75V and maximum 5V.
- Internal or external acquisition control with 6 μs conversion time supporting 100 ksps sampling rate.
- Suitable for industrial control, automated test equipment, robotics, telecommunications, and medical instruments.
- Temperature range from -40°C to 85°C ensures reliable operation in harsh environments.
- Parallel interface type in a compact 28-pin SOIC surface-mount package measuring 18.08mm x 2.64mm.
Product Description
Maxim Integrated MAX197BEWI+ is an advanced 12-bit Analogue to Digital Converter (ADC) designed for precision data acquisition in demanding industrial and instrumentation applications. This ADC features an 8-channel input with a successive approximation register (SAR) architecture, delivering reliable and accurate 12-bit resolution and fast 100 ksps sampling rates.
The device operates on a single +5V power supply (4.75V minimum, 5V maximum) and offers software-selectable input voltage ranges such as ±10V, ±5V, 0V to 10V, and 0V to 5V, making it versatile for various signal types. Its fault-protected input multiplexer tolerates input voltages up to ±16.5V, protecting the device from potential damage in industrial environments. The MAX197BEWI+ supports internal or external reference voltages and clocking, allowing flexible integration into custom systems.
Encased in a 28-pin SOIC package measuring 18.08 mm in length and 2.64 mm in height, it is designed for surface mounting on PCBs to optimize space. The parallel interface ensures rapid data transfer suitable for high-speed applications.
The device maintains operational performance across a wide temperature range from -40°C to 85°C, aligning with requirements for industrial and medical instrument use. Typical applications include automated test equipment (ATE), robotics control, telecommunications systems, data acquisition systems, and industrial control systems.
High precision 12-bit SAR ADC architecture ensures accurate data conversion. Eight analog input channels with fault-protected input multiplexer. Flexible input voltage ranges selectable via software. Operates on a stable +5V power supply with a parallel interface.
Compact 28-pin SOIC surface-mount package ideal for PCB integration. Wide operating temperature range for robust industrial application. 6 μs conversion time enabling 100 ksps sample rates for fast data acquisition. Supports internal or external reference and clock control options.
Choose the MAX197BEWI+ ADC for precision and reliability in your electronic measurement and control systems. Explore more semiconductor and converter products available at EnvMart for diverse industrial and laboratory needs.
