TDK 1008 Shielded Wirewound Surface Mount Inductor with Ferrite Core 33 μH ±10 % 85 mA NLFV25T-330K-EF

TDK NLFV25T-330K-EF is a high-quality 1008 shielded wirewound surface mount inductor featuring a ferrite core, offering 33 μH inductance with a ±10 % tolerance and a maximum current rating of 85 mA. This resin mold type wound inductor is designed specifically for decoupling circuits requiring stable inductance and minimal electromagnetic interference.

Its compact dimensions of 2.5 mm length, 1.8 mm height, and 2 mm depth make it ideal for space-constrained applications on printed circuit boards. The magnetic shielding incorporated in the exterior mold resin containing ferrite powder significantly reduces noise and signal disturbances, making it suitable for sensitive electronics.

Operating within a temperature range of -40°C to 105°C, including self-temperature rise, the NLFV25T-330K-EF ensures reliability in a wide range of industrial, telecommunications, and consumer electronic environments. It features a maximum DC resistance of 1.68 Ω and a maximum self-resonant frequency of 2.52 MHz, enabling effective filtering in high-frequency circuits.

The device is designed for surface mount termination style and comes packaged in tape & reel, facilitating automated assembly processes. Applications include smart metering devices, audio-video equipment, xDSL modems, mobile base stations, industrial machinery, and various communication infrastructure equipment.

Manufactured in Japan, this inductor complies with RoHS standards emphasizing environmental compliance and safety. This inductor features a 1008 package size suitable for surface mount technology. Constructed with a ferrite core and wirewound coil ensuring robust magnetic performance.

Designed with magnetic shielding for reduced electromagnetic interference. Operates reliably from -40°C up to 105°C, including self-temperature rise. Maximum DC resistance is 1.68 Ω, optimizing efficiency for decoupling circuits.

Provides a maximum self-resonant frequency of 2.52 MHz for high-frequency applications. Packaged in tape and reel format for automated assembly lines. Manufactured in Japan with RoHS compliance ensuring environmental safety.

Explore the range of Surface Mount Inductors at EnvMart for other high-performance components suitable for industrial, telecommunications, and electronic manufacturing applications.
