ASSMANN WSW Right Angle 15 Way 2.77 mm Pitch High Density Through Hole D-Sub Connector Male/Female A-DF 15 A/KG-F
Specifications
| Country of Origin | China |
|---|---|
| Voltage | 250.0V |
| Brand | ASSMANN WSW |
| Orientation | Right Angle |
| Current | 3A |
| Model | A-DF 15 A/KG-F |
| Mount Type | Through Hole |
| Housing Material | Metal |
| Contact Material | Brass |
| Series | A-DF |
| Termination Type | Solder |
| Maximum Operating Temperature | 85°C |
| Minimum Operating Temperature | -20°C |
| Pitch | 2.77mm |
| Contact Plating | Gold, Nickel |
| Number of Contacts | 15 |
| Contact Gender | Female |
| Connector Gender | Male/Female |
| Connector Type D | D-Sub |
Key Features
- This connector features a right angle orientation enhancing PCB mounting options.
- Its metal housing ensures robust mechanical protection and EMI shielding.
- Contacts are brass with gold and nickel plating for superior conductivity and corrosion resistance.
- Supports up to 3A current and 250 V voltage, suitable for moderate power applications.
- Termination by solder type enables strong, durable connections.
- Designed to operate reliably from -20°C to 85°C across various industrial environments.
- Male/female gender connectors offer flexible mating configurations.
- High-density design optimizes space without compromising performance.
Product Description
ASSMANN WSW A-DF 15 A/KG-F is a right angle high density 15 way D-Sub connector designed for through hole PCB mounting with a 2.77 mm pitch. Manufactured with a metal housing and brass contacts featuring gold and nickel plating, this connector ensures enhanced durability and excellent electrical performance in a variety of electronic and industrial applications.
Operating with a current rating of 3A and voltage rating of 250 V, it supports reliable signal and power transmission. The solder termination type secures the connector firmly to PCBs, while operational temperature range from -20°C to 85°C makes it suitable for a wide range of environments.
The male/female contacts provide flexible mating options, and the right angle orientation helps in efficient PCB layout designs. The connector is part of the A-DF series, known for precision and high quality.
This product is ideal for integration in electronic devices, industrial controls, power supplies, and computing connectors. High density pin configuration saves space and facilitates complex circuit connections. Robust metal housing offers strong mechanical resistance and electromagnetic interference protection.
The connector’s reliable construction ensures long service life and consistent electrical contact. Kit includes a 15 pin right angle connector suitable for through hole soldering.
Manufactured in China, this component is widely used across industries requiring dependable D-Sub Connectors for signal and power applications. It aligns with industrial standards though no specific certifications are listed.
Explore the comprehensive range of ASSMANN WSW connectors at EnvMart for precision electronic component solutions tailored to industrial and commercial needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
It supports a current rating of 3A and a voltage rating of 250V, making it suitable for moderate power applications.
This connector features a right angle orientation, which enhances PCB mounting options.
The housing is made of metal, and the contacts are brass with gold and nickel plating for improved conductivity and corrosion resistance.
The pitch size of this connector is 2.77 mm, which is designed for high-density applications.
It operates reliably within a temperature range of -20°C to 85°C, suitable for various industrial environments.
The connector utilizes a solder termination type, ensuring strong and durable connections to PCBs.
This connector has 15 contacts, allowing for complex circuit connections in a compact design.
It features male/female gender connectors, providing flexible mating configurations for various applications.
Yes, it is designed for integration in electronic devices, industrial controls, power supplies, and computing connectors.
The metal housing offers robust mechanical protection and electromagnetic interference (EMI) shielding.
This connector is manufactured in China.
It is part of the A-DF series, known for its precision and high-quality design.
