Igus Chainflex CF130.UL PVC Control Cable, 2 Cores, 0.34 mm² 22 AWG, Unscreened, 25 m, Grey Thermoplastic CF130.03.02.UL
Specifications
| Country of Origin | Germany |
|---|---|
| Voltage | 300V |
| Brand | Igus |
| Model | CF130.03.02.UL |
| Cable Length | 25m |
| Series | Chainflex CF130.UL |
| Outside diameter | 4.5mm |
| Maximum Operating Temperature | 70°C |
| Number Of Cores | 2 |
| Conductor Material | Bare Copper |
| Minimum Operating Temperature | -5°C |
| Jacket Material | Thermoplastic Elastomer |
| Outer Sheath | Low-adhesion mixture on the basis of PVC, adapted to suit the requirements in Energy Chains® (following DIN VDE 0282 Part 10) |
| Standards/Approvals | CE, EN |
| Jacket Colour | Grey |
| Fire Behaviour | Flame Retardant |
| American Wire Gauge | 22AWG |
| Screened/Unscreened | Unscreened |
| Conductor Type | Stranded |
| Cable CSA | 0.34mm² |
Key Features
- The cable is silicon-free, ensuring no influence from oils in the application environment.
- It is torsion resistant and flame-retardant to IEC 60332-1-2, CEI 20-35, FT1, and VW1 standards.
- Ideal for indoor applications with freely suspended travel distances and gliding applications up to 50 m.
- Constructed with fine-wire stranded bare copper conductors following EN 60228.
- The outer sheath is a low-adhesion PVC mixture, adapted for use in energy chains as per DIN VDE 0282 Part 10.
- The cable supports a voltage rating of 300 V and operates reliably in temperatures from -5°C to 70°C.
- The grey thermoplastic elastomer jacket provides durability and flexibility for various industrial uses.
Product Description
Igus CF130.03.02.UL Chainflex PVC Control Cable is engineered for reliable medium load automation and control applications. This control cable features 2 cores with 0.34 mm² fine-wire stranded bare copper conductors rated to 300 V and an American Wire Gauge of 22 AWG. It is unscreened and designed with a flame-retardant, grey thermoplastic elastomer sheath that provides excellent resistance against mechanical wear, oil influence, and environmental stress.
The cable is silicon-free, ensuring compatibility with sensitive environments and eliminating oil contamination. Its torsion resistance and low adhesion outer sheath allow smooth operation in energy chains with freely suspended travel distances and gliding applications up to 50 meters.
Operating temperature ranges from -5°C minimum to 70°C maximum, making it suitable for indoor industrial automation, laboratory, manufacturing, and electrical control systems. It complies with key fire and safety standards IEC 60332-1-2, CEI 20-35, FT1, and VW1, enhancing installation safety.
The fine-wire stranded conductor complies with EN 60228 and the outer sheath is specially formulated PVC optimized according to DIN VDE 0282 Part 10 for Energy Chains, ensuring flexibility and durability in demanding conditions.
The cable is silicon-free, preventing oil interference in sensitive systems. Torsion resistant construction enhances durability in dynamic applications. Flame retardant to IEC 60332-1-2 for enhanced safety. Suitable for indoor control cable applications and automation systems.
25 m length with grey thermoplastic elastomer sheath optimized for Energy Chains.
This model is manufactured in Germany and comes as a new product. It is ideal for industrial control, automation wiring, electrical panel wiring, and process control where flexible, durable cables are required.
Explore more high-quality Control Cables and wiring solutions at EnvMart for your industrial and electrical needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The cable supports a voltage rating of 300 V.
The maximum operating temperature is 70°C.
This control cable features 2 cores.
The outside diameter of the cable is 4.5 mm.
The conductors are made of fine-wire stranded bare copper, and the outer sheath is a low-adhesion PVC mixture.
This model is designed for indoor applications and is not specified for outdoor use.
It complies with IEC 60332-1-2, CEI 20-35, FT1, and VW1 standards for flame retardancy.
The cable length is 25 meters.
The American Wire Gauge rating for this cable is 22 AWG.
It is suitable for medium load automation and control applications, including electrical panel wiring and process control.
The minimum operating temperature is -5°C.
This control cable is unscreened.
