Molex Mini-Fit Jr PCB Header 6 Contacts 4.2 mm Pitch 2 Row Shrouded Through Hole 600V 9A 39-29-9063
Specifications
| Country of Origin | Mexico |
|---|---|
| Voltage | 600V |
| Brand | Molex |
| Orientation | Straight |
| Current | 9A |
| Mount Type | Through Hole |
| Housing Material | Nylon |
| Contact Material | Brass |
| Series | Mini-Fit Jr |
| Termination Type | Solder |
| Maximum Operating Temperature | 105°C |
| Minimum Operating Temperature | -40°C |
| Number of Rows | 2 |
| Pitch | 4.2mm |
| Contact Plating | Tin |
| Number of Contacts | 6 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Shrouded |
| Connector System | Wire-to-Board |
Key Features
- Supports up to 9A current per circuit ensuring reliable power transmission.
- Features 6 male contacts arranged in 2 straight rows with 4.2 mm pitch.
- Constructed with durable nylon housing and brass contacts plated with tin.
- Designed with scoop-proof, fully isolated terminals to prevent contact damage.
- Includes positive locking mechanism with audible click for secure mating.
- Operates safely within temperature range of -40°C to 105°C.
- Meets 600V voltage rating suitable for industrial and consumer electronics.
- Shrouded design provides additional protection and prevents mismating.
Product Description
Molex 39-29-9063 Mini-Fit Jr PCB Header is a durable 6-contact connector designed for wire-to-board applications with a 4.2 mm pitch, arranged in 2 straight rows. It is engineered to handle currents up to 9A per circuit at voltages up to 600V, making it ideal for both consumer and industrial electronic equipment.
The connector features a robust nylon housing which is scoop-proof to prevent damage to the brass male contacts plated in tin. Fully isolated terminals protect against debris and arcing, ensuring longevity and reliability.
This PCB header incorporates polarization and keying features to avoid misalignment or mismating, and a positive locking mechanism with an audible click confirms a secure connection, preventing accidental unmating due to shock or vibration.
Designed to operate between -40°C and 105°C, this connector is suited for a wide range of demanding applications including industrial automation equipment, office machinery, rack-mount servers, routers, switches, and consumer white goods.
The through hole mount type ensures stable installation on printed circuit boards, while the shrouded design adds an extra layer of protection to the terminals. Versions with snap-in plastic PCB peg locks and mounting flanges are available for enhanced retention.
Supports up to 9A current per circuit ensuring reliable power transmission. Features 6 male contacts arranged in 2 straight rows with 4.2 mm pitch. Constructed with durable nylon housing and brass contacts plated with tin.
Designed with scoop-proof, fully isolated terminals to prevent contact damage. Includes positive locking mechanism with audible click for secure mating. Operates safely within temperature range of -40°C to 105°C. Meets 600V voltage rating suitable for industrial and consumer electronics.
Shrouded design provides additional protection and prevents mismating. Through hole mount type for stable PCB installation.
Suitable for applications in industrial networks, automation, and consumer electronics, the Molex Mini-Fit Jr connector series offers reliable and flexible interconnection solutions.
Explore other high-quality PCB connectors and components in our Electronics & Electricals category at EnvMart.
Explore more products in our PCB Headers category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model supports a maximum current of 9A per circuit, ensuring reliable power transmission.
It is rated for a maximum voltage of 600V, making it suitable for industrial and consumer electronics applications.
The contacts are arranged with a pitch of 4.2 mm, which is standard for this type of connector.
This unit features 6 male contacts arranged in 2 straight rows.
The housing is made of durable nylon, and the contacts are brass plated with tin.
It utilizes a through hole mount type for stable installation on printed circuit boards.
It operates safely within a temperature range of -40°C to 105°C.
Yes, it has a shrouded design and incorporates polarization and keying features to avoid misalignment or mismating.
It uses a solder termination type, which is common for PCB connectors.
Yes, it includes a positive locking mechanism with an audible click to confirm secure mating and prevent accidental unmating.
The country of origin for this product is Mexico.
It is suitable for a wide range of applications including industrial automation equipment, office machinery, and consumer electronics.
