Molex Mini-Fit Jr Series Right Angle Through Hole PCB Header, 16 Contacts, 4.2 mm Pitch, 2 Row, Shrouded 39-29-1167
Specifications
| Country of Origin | China |
|---|---|
| Voltage | 600V |
| Brand | Molex |
| Orientation | Right Angle |
| Current | 6A |
| Mount Type | Through Hole |
| Housing Material | Nylon |
| Contact Material | Brass |
| Series | Mini-Fit Jr |
| Termination Type | Solder |
| Maximum Operating Temperature | 105°C |
| Minimum Operating Temperature | -40°C |
| Number of Rows | 2 |
| Pitch | 4.2mm |
| Contact Plating | Tin |
| Number of Contacts | 16 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Shrouded |
| Connector System | Wire-to-Board |
Key Features
- Supports up to 6A current per contact ensuring robust power delivery.
- Constructed with nylon housing for durability and insulation.
- Right angle orientation allows compact PCB mounting.
- Shrouded design provides protection from debris and supports scoop-proof housing.
- Features brass contacts plated with tin for reliable conductivity.
- Through hole mount type ensures sturdy physical and electrical connection.
- Operating temperature ranges from -40°C to 105°C suitable for diverse environments.
- Includes polarization and keying to prevent misalignment and mismating.
Product Description
Molex 39-29-1167 Mini-Fit Jr Series Right Angle Through Hole PCB Header is a high-quality PCB connector designed for demanding electronic applications. This shrouded header has 16 contacts arranged in 2 rows with a 4.2 mm pitch and is engineered to handle up to 6 amperes per circuit, making it suitable for power delivery in compact electronic assemblies.
The housing is made of durable nylon material that meets UL94V-0 and UL94V-2 standards, providing electrical insulation and mechanical robustness. Its right angle orientation facilitates efficient PCB layout in space-constrained designs. The shrouded and scoop-proof housing protects contacts against debris and damage during mating operations, ensuring long-term reliability.
Brass contacts with tin plating offer excellent conductivity and resistance to corrosion. The connector system is wire-to-board type with through hole mount style, allowing strong mechanical and electrical connection with PCB soldering. The connector also incorporates polarization and keying features, preventing incorrect mating and ensuring secure lock-in with an audible click confirmation.
Designed to operate within a temperature range from -40°C up to 105°C, this PCB header is suitable for diverse industrial, consumer electronics, office equipment, and automation applications requiring reliable power connections. Its robust design supports use in industrial automation equipment, networking hardware, routers, switches, and white goods.
Supports up to 6A current per contact ensuring robust power delivery. Durable nylon housing providing excellent insulation and protection. Right angle orientation optimizes PCB space usage. Shrouded and scoop-proof design prevents pin damage.
Brass contacts with tin plating for durable conductivity. Through hole mounting ensures strong physical and electrical connection. Wide operating temperature range from -40°C to 105°C. Polarization and keying prevent wrong mating and ensure secure connection.
Positive locking with audible click confirms full mating. Ideal for high current wire-to-board applications in industrial and electronic sectors. Explore Molex products and similar PCB connectors at EnvMart for reliable and certified electronic component solutions.
Explore more products in our PCB Headers category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This PCB header supports up to 6A current per contact, ensuring robust power delivery in electronic applications.
The contacts in this model are arranged with a pitch of 4.2 mm, which is standard for many PCB applications.
It utilizes a through hole mount type, allowing for a strong physical and electrical connection when soldered to the PCB.
The housing is constructed from nylon, while the contacts are made of brass with tin plating for reliable conductivity.
It operates within a temperature range from -40°C to 105°C, making it suitable for diverse environments.
Yes, it incorporates polarization and keying features to prevent misalignment and mismating during connection.
This model has a total of 16 contacts arranged in 2 rows.
The header is designed with a right angle orientation, which optimizes space usage on the PCB.
The voltage rating for this PCB header is 600V, making it suitable for various high-voltage applications.
It is a wire-to-board connector system, allowing for secure connections between wires and the PCB.
The shrouded design provides protection from debris and supports scoop-proof housing, enhancing the reliability of connections.
The country of origin for this PCB header is China.
