Molex Micro-Fit 3.0 Series Right Angle Through Hole PCB Header 10 Contacts 3 mm Pitch 2 Row Shrouded 43045-1002
Specifications
| Country of Origin | Mexico |
|---|---|
| Voltage | 250V |
| Brand | Molex |
| Orientation | Right Angle |
| Current | 5A |
| Mount Type | Through Hole |
| Housing Material | High Temperature Thermoplastic |
| Contact Material | Brass |
| Series | Micro-Fit 3.0 |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -40°C |
| Number of Rows | 2 |
| Pitch | 3mm |
| Contact Plating | Gold |
| Number of Contacts | 10 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Shrouded |
| Connector System | Wire-to-Board |
| Mating Pin Length | 3mm |
Key Features
- The PCB header features a right angle orientation with two rows and shrouded housing for secure mating.
- Contacts made of brass are gold plated to ensure reliable connectivity and corrosion resistance.
- The housing is constructed from high temperature thermoplastic capable of withstanding up to 125°C.
- This connector supports currents up to 5A and a voltage rating of 250V.
- It includes snap-in plastic peg PCB locks for secure PCB mounting.
- The PCB header is compatible with through hole mounting, also SMT compatible for manufacturing flexibility.
- Minimum operating temperature is -40°C, suitable for a range of environmental conditions.
- Positive latching prevents accidental disconnects, ensuring stable electrical performance.
Product Description
Molex 43045-1002 is a Micro-Fit 3.0 Series right angle through hole PCB header designed for wire-to-board applications, featuring 10 contacts arranged in 2 rows with a 3 mm pitch. It provides a compact, reliable connection suitable for low to mid-range power distribution in electronics.
The header uses a shrouded housing made from high temperature thermoplastic that withstands temperatures up to 125°C during soldering processes, enhancing durability in harsh manufacturing environments. The brass contacts are gold plated to ensure consistent conductivity and corrosion resistance.
It supports a current rating of 5 Amperes and a voltage rating of 250 Volts, making it suitable for a wide range of industrial and commercial applications, including consumer electronics, data communications, medical devices, telecommunications, and solar power systems.
The right angle orientation and through hole mount type provide flexible PCB integration, while plastic peg PCB locks secure the connector firmly in place. Minimum operating temperature of -40°C allows operation in harsh environments. The connector features positive latching for secure mating and prevents accidental disconnection.
The compact design supports high current carrying capacity in a small footprint. High temperature housing supports IR reflow soldering processes. Through hole mounting versions are SMT compatible to reduce assembly costs.
Positive latching ensures secure connections. Plastic peg locks prevent connector movement on PCB. Made in Mexico maintaining high manufacturing standards.
This PCB header is ideal for industrial, laboratory, construction, telecom, and commercial electronics manufacturing, providing a versatile and robust connector solution within the Micro-Fit 3.0 family.
Explore more PCB connectors and electronic components within the EnvMart portfolio to find compatible parts and accessories.
Explore more products in our PCB Headers category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The voltage rating of this PCB header is 250V.
It can support a maximum current of 5A.
The pitch of the contacts is 3 mm.
The contacts are made of brass and are gold plated, while the housing is constructed from high temperature thermoplastic.
The minimum operating temperature is -40°C, and the maximum operating temperature is 125°C.
This PCB header has 10 contacts arranged in 2 rows.
This model is compatible with through hole mounting and is also SMT compatible.
Yes, it includes plastic peg PCB locks for secure mounting and positive latching to prevent accidental disconnections.
The orientation of this PCB header is right angle.
This product is manufactured in Mexico.
It is suitable for a range of applications including consumer electronics, data communications, medical devices, telecommunications, and solar power systems.
The termination type for this connector is solder.
