Molex Micro-Fit 3.0 Series Right Angle Through Hole PCB Header 6 Contact 3 mm Pitch 2 Row Shrouded 43045-0623

Molex 43045-0623 Micro-Fit 3.0 Series PCB Header is a right angle, through hole connector featuring 6 male contacts arranged in 2 rows with a 3 mm pitch. The shrouded header is designed with high temperature thermoplastic housing that withstands up to 265°C for IR reflow soldering processes. Its brass contacts are gold plated to ensure excellent conductivity and resistance to corrosion.

This connector supports currents up to 5 amps with a voltage rating of 250 volts. The right angle orientation facilitates efficient wire-to-board connections and the shrouded design provides secure mating to prevent accidental disconnections. Metal press-fit retention clips are incorporated for enhanced mechanical retention on PCBs, reducing the risk of loosening under vibration or shock.

The Micro-Fit 3.0 series features fully isolated dual beam terminals that reduce electrical arcing and improve long-term contact reliability. Operating temperature ranges from -40°C to 125°C enable use in automotive, telecommunications, industrial, and consumer electronic applications. This series is often found in solar power systems, medical devices, routers, servers, and gaming equipment requiring compact and robust power distribution connectors.

This PCB header features a compact dual-row design with 3 mm pitch spacing for high-density applications. Constructed with high temperature thermoplastic housing suitable for IR reflow soldering. Supports up to 5A current capacity with gold plated brass contacts for reliable conductivity.

Right angle orientation provides easy wire-to-board connection with shrouded design for protection. Includes metal press-fit retention clips for enhanced PCB retention and durability. Operates reliably between -40°C and 125°C making it suitable for demanding environments.

Fully isolated dual beam terminals reduce arcing and ensure stable electrical performance. Widely used in telecommunications, consumer electronics, solar power, and gaming terminals.

This Molex Micro-Fit 3.0 Series PCB Header is ideal for industrial, commercial, and laboratory electronics applications where reliable power and signal connections are critical. Its robust construction and compact size meet the needs of modern electronics manufacturing processes including surface mount technology compatibility. Explore the full range of PCB connectors at EnvMart for compatible connectors and accessories.
