Texas Instruments Operational Amplifier 1.8 MHz, 8-Pin TO-263 Package 40V OPA452FAKTWT

Free Delivery in India | Lowest Global Shipping Charges

Texas Instruments Operational Amplifier 1.8 MHz, 8-Pin TO-263 Package 40V OPA452FAKTWT

Name: Texas Instruments Operational Amplifier 1.8 MHz, 8-Pin TO-263 Package 40V OPA452FAKTWT
Brand: Texas Instruments
SKU: 100442
Price: 9.23 USD
Availability: InStock



Category Operational Amplifier Brand Texas Instruments Condition New

Specifications

Country of Origin	India
Brand	Texas Instruments
Height	4.44mm
Length	10.1mm
Model	OPA452FAKTWT
Width	8.89mm
Mount Type	Surface
Series	OPA452
Output Current	50mA
Maximum Operating Temperature	125°C
Package Type	TO-263
Minimum Operating Temperature	-40°C
Number Of Channels	1
Standards/Approvals	RoHS
Pin Count	8
Maximum Supply Voltage	40V
Minimum Supply Voltage	10V
GBP - Gain Bandwidth Product	1.8MHz
Input Bias Current	±100 pA
Vos - Input Offset Voltage	±6 mV
Slew Rate	7.2V/μs

Key Features

High gain bandwidth product of 1.8 MHz ensures fast signal amplification.
Operates from a minimum supply voltage of 10V up to a maximum of 40V for broad application versatility.
Low input bias current of ±100 pA allows precise signal processing with minimal error.
Input offset voltage of ±6 mV and input offset current of ±100 pA contribute to high accuracy.
Slew rate of 7.2 V/μs supports rapid output voltage changes for dynamic signals.
Can deliver output current up to 50 mA suitable for driving low impedance loads.
Designed for operating temperatures between -40°C and 125°C for reliable industrial usage.
Compact package dimensions with 10.1 mm length, 8.89 mm width, and 4.44 mm height.

Product Description

Texas Instruments OPA452FAKTWT operational amplifier is a high voltage, high current device tailored for demanding industrial applications. This single-channel, 8-pin TO-263 surface mount amplifier provides a gain bandwidth product of 1.8 MHz, delivering reliable and efficient amplification in circuits that require fast dynamic response.

Operating from a supply voltage range of 10V to 40V, it handles output currents up to 50 mA, making it suitable for driving low impedance and difficult loads such as MOSFETs, power transistors, and bridge amplifier configurations. The device features low input bias and offset currents and voltages, which ensures accuracy and low signal distortion in precision electronics.

Its robust operating temperature range from -40°C to 125°C supports continuous operation in harsh environments encountered in industrial, automotive, and instrumentation systems. The compact TO-263 package, with dimensions 10.1 mm (L) x 8.89 mm (W) x 4.44 mm (H), facilitates easy PCB mounting and integration into complex assemblies.

The OPA452 series complies with RoHS standards, affirming its environmentally conscious design and manufacturing processes. Typical applications include power supplies, motor speed controllers, servo amplifiers, and instrumentation systems requiring high voltage and high current operational amplifiers.

High gain bandwidth product of 1.8 MHz ensures fast and reliable amplification. Wide supply voltage range from 10V to 40V supports diverse application scenarios. Low input bias current and offset enhance signal accuracy.

High slew rate of 7.2 V/μs suitable for rapid dynamic outputs. 50 mA output current capability for driving demanding loads. Robust operation over industrial temperature range (-40°C to 125°C). Compact 8-pin TO-263 surface mount package for efficient PCB layout.

RoHS compliant for environmentally friendly applications. Ideal for power transistor driving, bridge amplifiers, and servo amplifiers. Supports applications in industrial, instrumentation, and motor control systems. Explore the comprehensive range of Operational Amplifiers and semiconductor components on EnvMart to find the right solution for your electronic designs.
