Samtec SSW Series Straight Through Hole PCB Socket, 9-Contact, 1 Row, 2.54 mm Pitch, 4.7A, 655V, Solder SSW-109-01-T-S

Samtec SSW-109-01-T-S is a single row, straight through hole PCB socket designed for board-to-board connection applications. This socket features 9 female contacts arranged with a 2.54 mm pitch and supports a current of 4.7A at voltages up to 655V. It is suitable for various industrial, electronic, and manufacturing uses requiring reliable electrical connection with robust housing and contact system.

The housing material is Liquid Crystal Polymer, ensuring high performance in harsh environments with a temperature range from -55°C to 105°C. The contact system uses Tiger Buy™ technology, with bronze contacts plated in tin to deliver excellent conductivity and corrosion resistance. Standard solder termination and through-hole mount provide firm mechanical stability on the PCB.

This socket is designed with a straight orientation featuring a female contact gender, ideal for standard insertion applications. It supports both through-hole and surface mount terminations, and is available in single, double, or triple row versions, accommodating up to 150 pins. Standard and low insertion force versions are offered to reduce mating effort with compatible .025” square post terminals.

Applications include use in industrial electronic modules, power connectors, and control circuitry requiring reliable, high-performance PCB sockets. This model does not bear specific approvals or certifications but matches industry standard quality for PCB connectors.

9 contacts in one row with 2.54 mm pitch for standard PCB layouts. Supports a current rating of 4.7A, suitable for moderate power electronic circuits. Can withstand operating temperatures from -55°C to 105°C for versatile environmental use.

Constructed with durable Liquid Crystal Polymer housing for mechanical strength and thermal stability. Features Tiger Buy™ contact system with bronze, tin-plated contacts ensuring conductivity and corrosion resistance. Straight orientation and through-hole mounting ensure solid PCB connection integrity.

Supports solder termination with options for through-hole and surface mount terminations.

For engineers and designers, the Samtec SSW series is a reliable choice for board-to-board socket connection needs, suitable across electronics manufacturing, industrial control systems, and power delivery applications. Explore additional Samtec connectors and electronic components in the PCB Socket category on EnvMart.
