Samtec ST4 Series Straight Surface PCB Socket, 20-Contact, 2 Row, 0.4 mm Pitch, Solder Termination ST4-10-1.00-L-D-P-TR

Samtec ST4-10-1.00-L-D-P-TR is a high-precision straight surface PCB socket designed for board-to-board connector systems. This 20-contact, 2-row socket features an ultra-fine 0.4 mm pitch solder termination, making it ideal for compact and high-density PCB applications in electronics manufacturing.

The socket's housing is made from liquid crystal polymer, providing excellent mechanical strength and high thermal resistance, supporting operation between -55°C minimum and 125°C maximum. Its contacts are constructed from bronze with gold plating to ensure superior conductivity and long-term reliability in harsh environmental conditions.

This product supports a current rating of 1.6 A, catering to low-current electronic components. The stacking height of 6 mm and row pitch of 1.41 mm offer a slim footprint and effective space-saving on the PCB layout, important for modern compact electronic devices.

The surface mount design of the socket facilitates automated placement and soldering, making it suitable for industrial manufacturing processes. Featuring female contact gender and straight orientation, the connector ensures secure and precise mating with corresponding connectors.

As part of the Samtec ST4 series, this socket meets the demands of ultra-fine pitch terminal strips, enabling connections of up to 100 I/Os within a small footprint, which is essential for advanced electronic device prototyping and production.

Applications of this PCB socket span industrial electronics, communication devices, instrumentation, and other areas requiring highly reliable board-to-board connections in compact form factors.

Samtec's ST4-10-1.00-L-D-P-TR offers precision engineering and robust performance, making it a preferred choice for engineers and technicians in the electronics industry seeking ultra-fine pitch PCB sockets.

Explore more high-quality PCB Sockets and connectors to meet various electronic component assembly needs on EnvMart. The socket supports a current rating of 1.6 A suitable for low power applications. Manufactured using liquid crystal polymer housing for enhanced durability and thermal stability.

Designed with a stacking height of 6 mm and a row pitch of 1.41 mm to accommodate compact PCB layouts. Gold-plated bronze contacts ensure excellent conductivity and corrosion resistance. Operating temperature ranges from -55°C to 125°C, suitable for diverse environmental conditions.

Features female contact gender and a straight orientation for ease of PCB mounting. Surface mount configuration enables efficient automated assembly processes. Part of the ST4 series supporting ultra-fine 0.40 mm pitch terminal strips for high-density electronic designs.
