Nexperia 1, 10 V Single Zener Diode 250 mW 2% Tolerance Surface Mount 3-Pin SOT-23 BZX84-B10,215

Free Delivery in India | Lowest Global Shipping Charges

Nexperia 1, 10 V Single Zener Diode 250 mW 2% Tolerance Surface Mount 3-Pin SOT-23 BZX84-B10,215

Name: Nexperia 1, 10 V Single Zener Diode 250 mW 2% Tolerance Surface Mount 3-Pin SOT-23 BZX84-B10,215
Brand: Nexperia
SKU: 98368
Price: 0.07 USD
Availability: InStock



Category Zener Diode Brand Nexperia Condition New

Specifications

Country of Origin	China
Brand	Nexperia
Height	1.1mm
Length	3mm
Model	BZX84-B10,215
Mount Type	Surface
Series	BZX84
Maximum Operating Temperature	150°C
Package Type	SOT-23
Minimum Operating Temperature	-65°C
Pin Count	3
Number of Elements per Chip	1
Automotive Standard	AEC-Q101
Maximum Power Dissipation Pd	250mW
Diode Configuration	Single
Test Current It	5mA
Maximum Reverse Leakage Current	200nA
Nominal Zener Voltage Vz	10V
Zener Type	Voltage Regulator
Maximum Zener Impedance	20Ω
Typical Voltage Temperature Coefficient	6.4mV/°C

Key Features

Compact SOT-23 package with 3 pins for easy PCB mounting.
Nominal Zener voltage of 10 V suitable for voltage regulation tasks.
Maximum power dissipation rated at 250 mW ensuring reliable operation.
Low maximum reverse leakage current of 200 nA minimizes power loss.
Wide operating temperature range from -65°C to 150°C for harsh conditions.
Typical voltage temperature coefficient of 6.4 mV/°C for stable performance.
Complies with automotive standard AEC-Q101 ensuring quality and reliability.
Single diode configuration optimized for voltage regulation and protection circuits.

Product Description

Nexperia BZX84-B10,215 is a high-quality single Zener diode providing a nominal voltage of 10 V and power dissipation of 250 mW. Housed in a compact 3-pin SOT-23 surface mount package, this diode offers precise voltage regulation with a tight tolerance of ±2% and low reverse leakage current of 200 nA.

This diode is designed to operate reliably across a broad temperature range from -65°C to 150°C, making it well-suited for industrial, automotive, and consumer electronics applications that require robust voltage stabilization and protection.

The typical voltage temperature coefficient of 6.4 mV/°C ensures stable voltage characteristics under varying temperature conditions, while the maximum Zener impedance of 20 Ω supports effective regulation performance.

Its compliance with the automotive standard AEC-Q101 further guarantees high reliability in automotive and demanding embedded system environments. The surface mount SOT-23 form factor with 3 pins enables automated assembly on compact printed circuit boards, enhancing manufacturing efficiency for industrial electronics.

Compact SOT-23 3-pin surface mount package. Nominal voltage of 10 V with ±2% tolerance. Power dissipation rating of 250 mW. Broad temperature operating range: -65°C to 150°C. Low maximum reverse leakage current of 200 nA.

Typical voltage temperature coefficient: 6.4 mV/°C. Maximum Zener impedance: 20 Ω. Automotive standard compliant (AEC-Q101). Single diode configuration optimized for voltage regulation.

This Zener diode is applicable for voltage regulation, voltage reference, and overvoltage protection in industrial, automotive, consumer electronics, and power supply applications. Its reliable performance under demanding conditions makes it a versatile component for modern electronic design challenges.
