Wurth Elektronik Vertical Brass Screw Terminal, 50A, 2.54mm Pitch, M4 Screw Size, REDCUBE Series 74650074R
Specifications
| Country of Origin | India |
|---|---|
| Screw Size | M4 |
| Brand | Wurth Elektronik |
| Orientation | Vertical |
| Body Material | Brass |
| Current | 50A |
| Model | 74650074R |
| Series | REDCUBE |
| Number of Legs | 4 |
| Number of Rows | 2 |
| Pitch | 2.54mm |
| Body Plating | Tin |
Key Features
- Low profile design ensures compact PCB mounting.
- Constructed from brass with tin plating for durability and corrosion resistance.
- Features M4 screw size suitable for reliable fastening.
- Has 2 rows and 4 legs with a 2.54mm pitch for standardized PCB compatibility.
- Supports snap-in mounting for efficient assembly.
- Designed for automated pick and place and reflow soldering processes.
- High tightening torque offers stable mechanical connection.
- Reduces heat development for safer electrical operation.
Product Description
Wurth Elektronik 74650074R vertical brass screw terminal provides a robust solution for high current connections on printed circuit boards, rated for continuous currents up to 50A at 2.54mm pitch spacing. Manufactured from solid brass with tin plating, these terminals offer excellent conductivity and corrosion resistance.
The REDCUBE series terminals are milled from solid material, enabling a higher tightening torque and low heat generation under load, enhancing reliability in demanding industrial and electronic applications. Their low-profile form factor optimizes space utilization on multilayer PCBs.
Designed for automated assembly, these terminals support pick and place and reflow soldering methods, ensuring efficient manufacturing processes. The internal threading accepts an M4 screw size for secure wire retention and mechanical stability.
The terminal features 2 rows and 4 legs for stable board mounting and connectivity. It is suitable for diverse applications including industrial control systems, power electronics, laboratory instrumentation, and commercial electronic assemblies where high current rating and durability are critical.
Low profile design. High current rating of 50A. Constructed from brass with tin plating for enhanced durability. Internal M4 screw thread for strong wire connections. Supports automated pick and place and reflow soldering.
High mechanical stability on PCB due to design and materials. Internal threading enables higher tightening torque than stamped contacts. Reduces thermal stress on printed circuit boards. Compatible with multilayer PCB applications.
Snap-in feature for simplified installation.
The package contains one Wurth Elektronik vertical brass screw terminal model 74650074R as detailed. Its reliable construction and design tailor it for high-performance electronic and industrial power connector applications.
Explore more in the Electronics Components category at EnvMart to find additional high-quality connectors and terminals for your industrial and electronic needs.
Explore more products in our Wire Terminals & Splices category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model is rated for continuous currents up to 50A.
The terminal has a pitch size of 2.54mm, which is standardized for PCB compatibility.
It accepts an M4 screw size for secure wire retention and mechanical stability.
The terminal features 4 legs and 2 rows, providing stable board mounting and connectivity.
It is constructed from brass with tin plating, which enhances durability and corrosion resistance.
Yes, it is designed to support automated pick and place and reflow soldering methods, ensuring efficient manufacturing.
The terminal has a low-profile design that optimizes space utilization on multilayer PCBs, although specific dimensions are not provided.
It is suitable for industrial control systems, power electronics, laboratory instrumentation, and commercial electronic assemblies.
The terminal is manufactured in India.
Yes, its design reduces thermal stress on printed circuit boards during operation.
The internal threading allows for a higher tightening torque compared to stamped contacts, enhancing mechanical stability.
It supports snap-in mounting for simplified installation on PCBs.
