Wurth Elektronik WE-GF Series Shielded Wirewound Surface Mount Inductor, 4.7μH ±10% 220mA Ferrite Core 1210 Package 74476404
Specifications
| Country of Origin | China |
|---|---|
| Brand | Wurth Elektronik |
| Height | 2.2mm |
| Length | 2.9mm |
| Model | 74476404 |
| Depth | 2.5mm |
| Packaging | Tape & Reel |
| Series | WE-GF |
| Maximum Operating Temperature | 105°C |
| Minimum Operating Temperature | -40°C |
| Core Material | Ferrite |
| Inductance | 4.7μH |
| Package/Case | 1210 |
| Maximum DC Current | 220mA |
| Pin Count | 2 |
| Maximum DC Resistance | 1500mΩ |
| Inductance Tolerance | ±10 % |
| Termination Style | Surface Mount |
| Maximum Self Resonant Frequency | 58MHz |
| Minimum Quality Factor | 30 |
| Inductor Construction | Wirewound |
Key Features
- Shielded wirewound surface mount inductor suitable for high frequency applications.
- Designed with ferrite core material for efficient magnetic performance.
- Rated inductance of 4.7μH with ±10% tolerance for reliable operation.
- Maximum DC current of 220mA enables robust performance in HF circuits.
- 1210 package supports convenient mounting on PCBs for compact electronic designs.
- Operating temperature range from -40°C to 105°C, ensuring stable performance.
- Maximum DC resistance of only 1.5Ω provides low losses for circuit efficiency.
- Surface mount termination allows automated manufacture and efficient PCB layout.
Product Description
Wurth Elektronik 74476404 Shielded Wirewound Surface Mount Inductor, part of the reliable WE-GF series, is engineered for demanding high-frequency electronic applications. Featuring a ferrite core, this component offers a rated inductance of 4.7μH with a tight ±10% tolerance for precise signal control. The inductor supports a maximum DC current of 220mA and comes in a compact 1210 package, making it a perfect fit for modern PCB assemblies in industrial and advanced laboratory environments.
The wirewound and shielded construction ensures reduced electromagnetic interference, enhancing circuit stability in sensitive applications. Its surface mount termination style simplifies automated production, speeding up manufacturing processes while yielding reliable solder joints.
Shielded wirewound inductor for high-frequency signal integrity. Ferrite core delivers high performance and minimal losses. Inductance of 4.7μH ±10% and 220mA maximum DC current. 1210 (3225 metric) SMD package for compact PCBs.
Suitable for HF amplifiers, oscillators, LC filter circuits, and transponders. Wide operating temperature range from -40°C to 105°C. Low DC resistance (max. 1.5Ω) for efficient operation. Molded body construction increases robustness and longevity.
Complies with modern industry standards for quality factor and resonance. Surface mount design allows for integration in dense electronic layouts.
This Wurth Elektronik WE-GF series inductor is ideal for industrial, laboratory, and electronic manufacturing use cases, including RF circuit design, PCB assembly, and signal conditioning in adapter networks or tuners. The device is particularly appropriate where low resistance, high quality factor, and compact size are required.
Browse more Wurth Elektronik inductors and Surface Mount Inductor components for advanced circuit designs on EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The inductor has a rated inductance of 4.7μH with a tolerance of ±10%.
This model supports a maximum DC current of 220mA, allowing for robust performance in high-frequency circuits.
The operating temperature range for this inductor is from -40°C to 105°C, ensuring stable performance across various conditions.
The maximum DC resistance is 1.5Ω, which contributes to low losses and efficient operation.
It features a ferrite core material, which is designed for efficient magnetic performance.
This inductor comes in a 1210 package, which is suitable for compact PCB designs.
It has a surface mount termination style, which simplifies automated production and efficient PCB layout.
The maximum self-resonant frequency is 58MHz, making it suitable for high-frequency applications.
The minimum quality factor is 30, indicating its efficiency in signal integrity applications.
This model features a wirewound construction, which helps in reducing electromagnetic interference.
The inductor is packaged in tape and reel, facilitating easy handling and automated assembly processes.
It is suitable for high-frequency applications such as RF circuit design, oscillators, and LC filter circuits.
