Samtec Straight Surface Mount PCB Header, 10 Contacts, 2.54 mm Pitch, 2 Row, Shrouded IPL1
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 675V |
| Brand | Samtec |
| Orientation | Straight |
| Current | 3.8A |
| Model | IPL1 |
| Mount Type | Surface |
| Housing Material | Liquid Crystal Polymer |
| Contact Material | Phosphor Bronze |
| Series | IPL1 |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Mounting Angle | Straight |
| Number of Positions | 10 Position |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 2 |
| Pitch | 2.54mm |
| Termination Style | Solder |
| Contact Plating | Gold |
| Number of Contacts | 10 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Shrouded |
| Connector System | Wire-to-Board |
Key Features
- Offers a 2.54 mm pitch suitable for standard PCB connections.
- Equipped with 10 phosphor bronze male contacts for reliable conductivity.
- Shrouded, straight surface mount design ensures secure installation and protection.
- Gold contact plating improves corrosion resistance and electrical performance.
- Liquid crystal polymer housing supports durability under varying conditions.
- Handles up to 3.8A current and 675V voltage for high-density power applications.
- Rated for operation between -55°C and 125°C for versatile temperature environments.
- Solder termination style simplifies board-level assembly.
Product Description
Samtec IPL1-110-02-L-D-K-TR Straight Surface Mount PCB Header provides robust electrical connectivity for wire-to-board applications in industrial, laboratory, and commercial electronic equipment. Featuring 10 male contacts arranged in 2 rows, each spaced at a 2.54 mm pitch, the connector supports high-density mounting and streamlined integration into PCBs.
The shrouded header design ensures safer and more reliable connections, minimizing the risk of misalignment during installation. Gold-plated phosphor bronze contacts maintain optimal signal transfer by reducing electrical resistance and preventing corrosion, while the liquid crystal polymer housing offers excellent mechanical strength and thermal stability.
Rated for up to 3.8A current and 675V voltage, the IPL1-110-02-L-D-K-TR is suited for power and signal transmission in electronic assemblies. The straight orientation and surface mount configuration facilitate easy soldering and compatibility with automated manufacturing processes.
Operating within a temperature range of -55°C to 125°C, this PCB header is suitable for demanding environments encountered in industrial control panels, instrumentation, and advanced electronics. Its solder termination type makes board-level assembly efficient, reducing setup time in production lines.
2.54 mm pitch, 10 male contacts for standard PCB interface. Gold-plated phosphor bronze contacts for enhanced electrical endurance and reliability. Liquid crystal polymer housing increases chemical and thermal resistance.
Shrouded, straight surface mount design provides secure, professional board connectivity. Supports wire-to-board systems in industrial, laboratory, and commercial electronic sectors. Wide operating temperature range for robust performance.
Solder termination style compatible with automated PCB assembly.
This connector is commonly used in industrial electronic equipment, instrumentation, automation controllers, and advanced laboratory devices requiring secure and high-reliability PCB interconnections. Explore more PCB Headers and Samtec solutions in the Electronics Components category on EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The pitch of this PCB header is 2.54 mm, which is suitable for standard PCB connections.
This model features 10 male contacts arranged in 2 rows.
The maximum voltage rating for this connector is 675V.
It can handle up to 3.8A of current.
This PCB header uses a solder termination style, which simplifies board-level assembly.
The contacts are made of phosphor bronze and are gold-plated to enhance electrical endurance and reliability.
It is rated for operation between -55°C and 125°C, making it suitable for various temperature environments.
The housing is made of liquid crystal polymer, which provides excellent mechanical strength and thermal stability.
This connector is shrouded, which helps ensure safer and more reliable connections during installation.
It is commonly used in industrial electronic equipment, instrumentation, automation controllers, and advanced laboratory devices.
This model features a surface mount design, facilitating easy soldering and compatibility with automated manufacturing processes.
