| Country of Origin | China |
|---|---|
| Brand | Nexperia |
| Height | 0.8mm |
| Length | 1.8mm |
| Model | PMEG3005EJ,115 |
| Width | 1.35mm |
| Mount Type | Surface |
| Series | PMEG3005EJ |
| Maximum Operating Temperature | 150°C |
| Package Type | SOD-323 |
| Minimum Operating Temperature | -65°C |
| Pin Count | 2 |
| Maximum Continuous Forward Current If | 500mA |
| Peak Reverse Repetitive Voltage Vrrm | 30V |
| Diode Configuration | Single |
| Rectifier Type | Schottky |
| Peak Reverse Current Ir | 150μA |
| Peak Non-Repetitive Forward Surge Current Ifsm | 10A |
| Maximum Forward Voltage Vf | 430mV |
The Nexperia PMEG3005EJ,115 Schottky Diode is a compact, high-efficiency surface-mount component designed for demanding applications requiring fast switching, low forward voltage drop, and low leakage current. This diode operates at a maximum continuous forward current of 500mA and withstands up to 30V peak reverse repetitive voltage.
Featuring an ultra-small SOD-323 package with dimensions of 1.8mm length, 1.35mm width, and 0.8mm height, it is optimized for assembling compact PCBs where real estate is at a premium. With a maximum forward voltage of 430mV, the PMEG3005EJ,115 supports efficient operation by minimizing energy loss during conduction. Its low capacitance and low leakage current allow for high-speed rectification and switching with negligible power losses.
Designed to withstand demanding conditions, the operating temperature range extends from -65°C to 150°C, making it well-suited for industrial, electronics, and commercial environments. The diode supports a peak non-repetitive forward surge current of up to 10A, providing transient protection for circuits subjected to short-term current spikes.
Its single diode configuration and 2-pin design make integration straightforward in both new and legacy circuit layouts. The surface-mount feature simplifies automated assembly and enhances reliability. Typical applications include industrial equipment, power supplies, consumer electronics, and laboratory instrumentation where fast-acting rectifiers are required.
With compliance to high-performance standards and built for ultra-low profile mounting, the Nexperia PMEG3005EJ,115 Schottky Diode is a reliable choice for engineers designing efficient power conversion and signal rectification solutions.
Discover more Schottky Diodes and advanced semiconductor components from Nexperia and browse our full Electronics & Electricals category for tailored solutions across industrial, laboratory, and commercial sectors with EnvMart.
