Samtec Straight Through Hole Pin Header 20 Contacts 2.54 mm Pitch 1 Row Unshrouded TSW-120-08-G-S

The Samtec TSW-120-08-G-S is a high-quality straight through hole pin header designed for robust PCB connections in industrial and commercial electronics. This single-row header features 20 male contacts, with a 2.54 mm pitch, making it ideal for interfacing standard board layouts and signal transmissions.

Combining a glass filled polyester housing with gold plated phosphor bronze contacts, this header ensures both mechanical strength and electrical integrity. It supports through-hole mounting, allowing for firm board-to-board connection, and the unshrouded design offers easy access for soldering and mating connectors. The solder termination type facilitates secure installation and compatibility with a wide range of PCB systems.

The product is rated for operation across a wide temperature range, from -55°C to 125°C, supporting applications in demanding environments. With a maximum voltage rating of 550 V, it is suitable for both signal and moderate power circuits.

Extended Life Product with support for high mating cycles (250 - 2,500 cycles), ensuring durability in frequent-use scenarios. The .025" (0.635 mm) square post contact system delivers reliable connectivity, and the vertical orientation makes it fit for applications requiring straightforward mating alignment.

Typical use cases include industrial instrumentation, control systems, automotive electronics, manufacturing equipment, telecommunications, and laboratory interface boards. Its board-to-board connector system and male contact gender make it essential for PCB designs requiring stable, high-performance connections.

Single row with 20 contacts, ideal for industrial PCB designs. 2.54 mm pitch and 1 row layout simplifies circuit board integration. Glass filled polyester housing supports mechanical and thermal stability. Gold plated contacts enhance electrical performance and longevity.

Unshrouded configuration facilitates easy connector mating and replacement. Wide operating temperature range supports laboratory, manufacturing, and field electronics. Solder termination for reliable and secure board mounting.

Maximum voltage rating of 550 V, compatible with a variety of circuit designs. Explore more PCB Headers and interface solutions in the Samtec range at EnvMart for your industrial, laboratory, and electronics design requirements.
