STMicroelectronics Operational Amplifier 5.5 MHz, 14-Pin SOIC, 2.5-5.5V LMV824AIDT

STMicroelectronics LMV824AIDT is a high-accuracy, low power, general-purpose operational amplifier with a 5.5 MHz gain bandwidth product and a 14-pin SOIC surface mount package. It operates at supply voltages ranging from 2.5 V to 5.5 V and incorporates four amplifier channels, making it suitable for automotive, industrial, medical, and consumer electronics applications requiring precise signal amplification.

The device features a low input offset voltage of 0.8 mV maximum at 25°C, a high slew rate of 1.7 V/μs for excellent transient response, and rail-to-rail output capabilities for maximizing output signal swing. It is automotive qualified to the AEC-Q100 standard and operates reliably across a wide temperature range from -40°C to 125°C, ensuring stable performance in harsh environments.

The compact SOIC package, measuring 8.75 mm in length, 4 mm in width, and 1.65 mm in height, enables efficient PCB space usage. The LMV824AIDT also features low power consumption, with a maximum of 400 μA at 5 V, and a shutdown mode with minimal current draw of 50 nA, prolonging battery life in portable devices.

Key features include low input bias current (120 nA), low input offset current (30 nA), and a maximum output current of 21 mA, making it ideal for precision amplification with low noise. Its high electrostatic discharge tolerance enhances reliability in demanding industrial and automotive applications.

Low power consumption with a maximum current of 400 μA at 5 V. Wide supply voltage range from 2.5 V to 5.5 V ensures compatibility with various systems. Four independent amplifier channels in a single package. Compact 14-pin SOIC surface mount package for space-saving PCB designs.

High slew rate of 1.7 V/μs enables rapid signal response. Rail-to-rail output enhances the output voltage swing range. Automotive qualified to AEC-Q100 for reliable automotive applications. Wide operating temperature range from -40°C to 125°C supports harsh environments.

Low input offset voltage of 0.8 mV contributes to high accuracy amplification. High ESD tolerance provides robustness in industrial and automotive systems.

This operational amplifier is suitable for industrial, automotive, instrumentation, healthcare, and consumer electronics where precise analog signal amplification is critical. Its combination of low power consumption, wide supply voltage, and high accuracy makes it an excellent choice for a wide range of applications.

Explore more Operational Amplifiers and electronic components in the Electronics & Electricals category at EnvMart to find the ideal solution for your design requirements.
