Abracon 8 MHz Crystal Unit Surface Mount Tape & Reel 3-Pin 12.7mm x 4.7mm x 4.2mm ABLSG-8.000MHZ-D2Y-T

The Abracon ABLSG-8.000MHZ-D2Y-T is an 8 MHz crystal unit designed specifically for surface mount applications requiring compact size and high frequency stability. Packaged in a low profile tape and reel format, this 3-pin crystal unit measures 12.7 mm in length, 4.7 mm in width, and 4.2 mm in height, making it suitable for integration in space-constrained electronic assemblies.

With a frequency tolerance of ±20 ppm and stability up to ±30 ppm, it delivers precise oscillation needed in EMI sensitive applications such as computers, modems, microprocessors, wireless communication devices, and medical electronics. Its series resistance of 80 ohms provides reliable frequency control, and the operating temperature range from -40°C to 85°C ensures stable performance in varying environmental conditions.

This crystal unit complies with RoHS standards, ensuring the absence of hazardous substances and suitability in modern electronic devices. The ABLS series from Abracon is recognized for its low profile design and extended temperature stability options for a wide variety of industrial and commercial electronics applications.

This crystal offers a standard frequency of 8 MHz with ±20 ppm tolerance. It features a compact surface mount package type with tape and reel packaging suitable for automated placement. The device has low profile dimensions of 12.7 mm length, 4.7 mm width, and 4.2 mm height.

Operating temperature range from -40°C to 85°C supports a wide range of applications. A series resistance of 80 ohms ensures stable oscillation characteristics. The crystal is RoHS compliant, ensuring environmental safety standards.

It is optimized for EMI sensitive applications including computers, modems, microprocessors, and medical electronics.

This crystal unit is ideal for use in various industrial, laboratory, HVAC, telecommunications, and medical electronics products that demand precise timing and frequency control. Customers can rely on Abracon’s ABLSG series for compact, reliable, and stable crystal oscillators integrated into SMD configurations.
