OSI Optoelectronics Infrared Photodiode Surface Mount, 65° Half Sensitivity Angle, 970nm Peak Wavelength PIN-10DP
Specifications
| Country of Origin | United States |
|---|---|
| Diameter | 24.64mm |
| Brand | OSI Optoelectronics |
| Height | 1.03in |
| Length | 8mm |
| Model | PIN-10DP |
| Packaging | Tape & Reel |
| Width | 5mm |
| Mount Type | Surface |
| Series | Pin |
| Maximum Operating Temperature | 85°C |
| Minimum Operating Temperature | -25°C |
| Polarity | Reverse |
| Dark Current | 1nA |
| Standards/Approvals | RoHS |
| Number of Pins | 1 |
| Typical Rise Time | 1000ns |
| Typical Fall Time | 0.6ns |
| Wavelength of Peak Sensitivity | 970nm |
| Spectrums Detected | Infrared |
| Breakdown Voltage | 30V |
| Minimum Wavelength Detected | 350nm |
| Maximum Wavelength Detected | 1100nm |
| Angle of Half Sensitivity | 65 ° |
| OSI Optoelectronics PIN-10DP Infrared Photodiode, 65 °, SurfaceBrand | OSI Optoelectronics |
Key Features
- Designed for surface mounting with a 65° angle of half sensitivity.
- Peak wavelength sensitivity at 970nm with detection range from 350nm to 1100nm.
- Operates reliably between -25°C and 85°C ambient temperatures.
- Features low dark current of 1nA and low capacitance for enhanced signal integrity.
- Packaging includes tape and reel for ease of automated assembly.
- Typical rise and fall times are 1000ns and 0.6ns, respectively, enabling fast switching.
- Reverse polarity configuration and breakdown voltage of 30V.
- RoHS compliant and made in the United States.
Product Description
OSI Optoelectronics PIN-10DP infrared photodiode is engineered for high-speed optical detection applications requiring precise and reliable infrared sensing capabilities. It features a surface mount design with a 65° half sensitivity angle that allows for accurate directional response in compact electronic assemblies.
This photodiode exhibits a peak sensitivity wavelength at 970nm and detects infrared light across a broad spectrum ranging from 350nm to 1100nm, making it ideal for applications such as optical communications, pulse detection, bar code readers, and high-speed photometry. It maintains low dark current at 1nA and low capacitance which contributes to excellent signal-to-noise performance and fast response times, with typical rise and fall times of 1000ns and 0.6ns respectively.
The device operates reliably within a temperature range from -25°C up to 85°C, ensuring robust performance in varied environmental conditions. It is reverse polarity configured with a breakdown voltage rating of 30V. The PIN-10DP is RoHS compliant, emphasizing its adherence to environmental and safety standards.
Supplied in tape and reel packaging, this photodiode supports streamlined manufacturing processes and automated PCB assembly lines. Its precise characteristics and compact footprint make it an optimal component for industrial, medical, and communications equipment where dependable infrared detection is critical.
High-speed response with low capacitance for quick switching. Wide dynamic range and high responsivity for accurate infrared detection. Stable operation across a wide temperature range. Compact surface mount packaging to facilitate seamless PCB integration.
Application versatility including optical remote controls and medical equipment. Compliance with RoHS standards ensures eco-friendly production and disposal. Made in the United States, reflecting stringent manufacturing quality controls.
Explore a comprehensive range of Photodiodes and optoelectronic components at EnvMart for industrial, laboratory, and commercial applications.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The peak sensitivity wavelength of this photodiode is 970nm.
It detects infrared light across a range from 350nm to 1100nm.
The typical rise time is 1000ns and the fall time is 0.6ns.
It operates reliably between -25°C and 85°C.
The dark current is specified at 1nA.
The breakdown voltage is rated at 30V.
It is supplied in tape and reel packaging, facilitating automated assembly.
The dimensions are 8mm in length, 5mm in width, and 1.03 inches in height.
This model features a surface mount design.
Yes, it is RoHS compliant, ensuring adherence to environmental and safety standards.
It is suitable for applications such as optical communications, pulse detection, and bar code readers.
It has a reverse polarity configuration.
