OSI Optoelectronics Infrared Photodiode, 65 ° Angle of Half Sensitivity, Through Hole TO-5 Package PIN-DL-20C

OSI Optoelectronics PIN-DL-20C Infrared Photodiode with a 65 ° angle of half sensitivity is a precision electronic component designed for infrared detection in various industrial and laboratory applications.

This photodiode features a 4-pin through hole TO-5 package with tape and reel packaging, making it suitable for automated assembly processes.

Operating temperature ranges from -25°C to 85°C, enabling reliable performance in diverse environmental conditions. Its spectral sensitivity covers from ultraviolet at 320nm up to near-infrared at 1100nm, with a peak sensitivity at 670nm for efficient infrared light detection.

The device exhibits fast electrical characteristics including a typical rise time of 1μs and a fall time of 0.6ns, ensuring rapid signal response for precise measurements. With a low dark current of 0.5nA and a breakdown voltage of 30V under reverse polarity, this photodiode maintains high signal quality and stable operation.

Compact physical dimensions of 3.05mm height, 37.97mm length, and 34.04mm width facilitate integration into tight electronic circuits. Certified RoHS compliant, this photodiode meets environmental safety and quality standards.

Applications include beam alignment, position sensing, angle measurement, height detection, and motion analysis in industrial manufacturing, laboratory instruments, and electronic measurement systems.

Detects infrared spectrum with peak sensitivity at 670nm. Features 4-pin through hole TO-5 package suitable for tape and reel mounting. Operates between -25°C and 85°C for broad environmental compatibility. Exhibits fast response with typical rise time of 1μs and fall time of 0.6ns.

Capable of detecting wavelengths from 320nm to 1100nm providing wide spectral coverage. Has a low dark current of 0.5nA ensuring high signal-to-noise ratio. Breakdown voltage is rated at 30V with reverse polarity. Compact dimensions: height 3.05mm, length 37.97mm, width 34.04mm.

RoHS compliant ensuring environmental and safety standards. Manufactured in the United States with high reliability duo-lateral technology. Explore more Photodiodes and electronic components at EnvMart for reliable and advanced electronics manufacturing solutions.
