Panasonic PCB Power Relay, 18V dc Coil, 22A Switching Current, SPST ALFG1PF18
Specifications
| Country of Origin | Thailand |
|---|---|
| Brand | Panasonic |
| Height | 23.3mm |
| Length | 30.1mm |
| Model | ALFG1PF18 |
| Width | 15.7mm |
| Mount Type | PCB |
| Contact Material | Silver Alloy |
| Series | ALFG |
| Maximum Operating Temperature | 60°C |
| Contact Configuration | SPST |
| Minimum Operating Temperature | -40°C |
| Switching Current | 22A |
| Terminal type | Through Hole |
| Typical Applications | Solar inverter, Uninterriptible PSU's, Office equipment |
| Contact Resistance | 100mΩ |
| Standards/Approvals | UL, RoHS, VDE |
| Coil Resistance | 230Ω |
| Coil Voltage | 18V dc |
| Switching AC Voltage | 250V ac |
| Coil Power | 1.4W |
| Surge breakdown voltage | 6kV |
Key Features
- Compact design ideal for PCB mounting.
- Coil power consumption is low at 1.4W for energy efficiency.
- Supports switching AC voltage up to 250V and current up to 22A.
- Operates reliably in temperatures ranging from -40°C to 60°C.
- Contact resistance is minimal at 100mΩ ensuring efficient current flow.
- Silver alloy contact material enhances durability and conductivity.
- Surge breakdown voltage of 6kV for electrical protection.
- Typical applications include solar inverters, uninterruptible power supplies, and office equipment.
Product Description
Panasonic ALFG1PF18 PCB Power Relay features an 18V dc coil voltage and a 22A switching current in an SPST contact configuration suitable for demanding electrical and automation applications.
This ALFG series power relay includes a through-hole terminal type and a compact dimension set (30.1mm length, 15.7mm width, and 23.3mm height), making it suitable for PCB mounting in various devices.
The relay coil has a resistance of 230Ω and consumes a power of 1.4W, which contributes to an energy-efficient operation while maintaining performance. Its operating temperature range spans from -40°C minimum to 60°C maximum, allowing use in diverse environmental conditions.
The silver alloy contacts ensure longevity and reliable electrical connection with a low contact resistance of 100mΩ. The relay can handle switching currents up to 22A and AC voltages up to 250V with a surge breakdown rating of 6kV, offering robust electrical protection.
Designed for industrial and commercial applications, typical uses include solar power inverters, uninterruptible power supplies (UPS), and office electrical equipment. The high insulation resistance and reduced coil holding voltage help in saving equipment energy.
Compact power relay designed for PCB mounting. Low coil holding voltage reduces power consumption. High insulation resistance and surge breakdown voltage. Suitable for solar photovoltaic systems and UPS applications. Durable silver alloy contact material with low resistance.
Wide operating temperature range from -40°C to 60°C. Through-hole terminal type for secure PCB connection. Complies with UL, RoHS, and VDE standards for quality and safety.
This Panasonic PCB Power Relay provides reliable switching capabilities for a variety of industrial, commercial, and automation electrical equipment. Explore the full range of Power Relays and electrical components available at EnvMart for your projects.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The coil voltage of this power relay is 18V DC.
It can handle a maximum switching current of 22A.
This model features an SPST (Single Pole Single Throw) contact configuration.
The dimensions are 30.1mm in length, 15.7mm in width, and 23.3mm in height.
It operates reliably in temperatures ranging from -40°C to 60°C.
This relay uses a through-hole terminal type for secure PCB connection.
The contact resistance is minimal at 100mΩ, ensuring efficient current flow.
The surge breakdown voltage is rated at 6kV, providing electrical protection.
The coil power consumption is low at 1.4W, contributing to energy efficiency.
Typical applications include solar inverters, uninterruptible power supplies, and office equipment.
It complies with UL, RoHS, and VDE standards for quality and safety.
The contacts are made from silver alloy, enhancing durability and conductivity.
