Panasonic Shielded Wirewound Surface Mount Inductor with Metal Composite Core 33 μH ±20% 2.5A Idc ETQP4M
Specifications
| Country of Origin | India |
|---|---|
| Brand | Panasonic |
| Height | 4.5mm |
| Length | 6.5mm |
| Model | ETQP4M |
| Depth | 6mm |
| Packaging | Tape & Reel |
| Series | ETQP4M |
| Maximum Operating Temperature | 150°C |
| Minimum Operating Temperature | -40°C |
| Core Material | Metal Composite |
| Inductance | 33μH |
| Standards/Approvals | RoHS |
| Package/Case | Surface Mount |
| Maximum DC Current | 2.5A |
| Pin Count | 2 |
| Maximum DC Resistance | 189.2mΩ |
| Inductance Tolerance | ±20 % |
| Termination Style | Surface Mount |
| Inductor Construction | Wirewound |
| Automotive Standard | AEC-Q200 |
Key Features
- Equipped with a metal composite core for high heat resistance and reliability.
- Shielded construction reduces electromagnetic interference and improves noise filtering.
- Designed for operation up to 150°C, including self-generated heat.
- Features high vibration resistance due to integral construction.
- Compact size with dimensions 6.5mm length, 4.5mm height, and 6mm depth.
- Compliant with AEC-Q200 automotive standard for enhanced durability.
- Surface mount package with tape and reel packaging for automated assembly.
- Low maximum DC resistance of 189.2 mΩ for efficient performance.
Product Description
Panasonic ETQP4M Shielded Wirewound Surface Mount Inductor features a metal composite core designed to provide exceptional heat resistance and high reliability. This surface mount inductor delivers an inductance of 33 μH with a tolerance of ±20% and supports a maximum DC current of 2.5 A.
Its shielded construction effectively reduces electromagnetic interference, enhancing noise filtering performance in demanding electronic applications. The inductor is built with a wirewound construction and molded design that offers excellent vibration resistance and stability under thermal stress, enabling operation at temperatures up to 150°C including self-generated heat.
With compact dimensions of 6.5 mm length, 4.5 mm height, and 6 mm depth, the ETQP4M is well-suited for space-constrained circuit board designs. It meets the stringent automotive AEC-Q200 standard ensuring reliability in automotive and high-vibration environments.
This inductor is surface mount packaged and supplied on tape and reel, facilitating automated PCB assembly processes. Its low maximum DC resistance of 189.2 milliohms ensures efficient current flow and minimal power loss.
Metal composite core enhances durability and thermal management. Shielded construction minimizes noise and interference. Robust wirewound and molded construction ensures vibration resistance. AEC-Q200 certified for automotive reliability.
Compact surface mount package suitable for dense circuitry. Operates reliably at temperatures from -40°C to 150°C. Low DC resistance for efficient power handling. Ideal for noise filtering in high-current, high-temperature circuits.
This Panasonic ETQP4M inductor is an essential component for industrial, automotive, and high-performance electronic applications requiring robust inductors with stable inductance and thermal endurance. Browse the Electronics & Electricals categories on EnvMart for more Surface Mount Inductors and related components.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The ETQP4M inductor has an inductance value of 33 μH with a tolerance of ±20%.
This model supports a maximum DC current of 2.5 A.
The dimensions of this inductor are 6.5 mm in length, 4.5 mm in height, and 6 mm in depth.
It operates reliably within a temperature range of -40°C to 150°C, including self-generated heat.
The ETQP4M features a wirewound construction with a metal composite core, providing high heat resistance and reliability.
The shielded construction reduces electromagnetic interference, enhancing noise filtering performance in electronic applications.
Yes, it complies with the AEC-Q200 automotive standard, ensuring reliability in automotive applications.
The maximum DC resistance is 189.2 mΩ, which ensures efficient performance.
This inductor is packaged in tape and reel format, facilitating automated assembly processes.
It is suitable for industrial, automotive, and high-performance electronic applications requiring robust inductors with stable inductance.
The pin count for this model is 2.
It meets RoHS standards, ensuring compliance with environmental regulations.
