Panasonic Short Hinge Lever Micro Switch, Solder Terminal, 100mA, 250V AC, 30V DC, SPCO AVT321461-A
Specifications
| Country of Origin | Thailand |
|---|---|
| Brand | Panasonic |
| Model | AVT321461-A |
| Series | AVT |
| Maximum Operating Temperature | 85°C |
| Contact Configuration | SPCO |
| Actuator Type | Short Hinge Lever |
| Minimum Operating Temperature | -25°C |
| Terminal type | Solder |
| Standards/Approvals | CSA, RoHS, UR, VDE |
| Contact DC Voltage | 30V dc |
| Switch Contact Current | 100mA |
| Operating Force | 0.39N |
| Mechanical Life | 500000Operations |
| Contact AC Voltage | 250V ac |
| Microswitch Type | Subminiature |
Key Features
- Featuring a short hinge lever actuator for precise actuation.
- Equipped with solder terminals for secure electrical connections.
- Configured as SPCO contact type for versatile switching.
- Operates reliably within temperature range from -25°C to 85°C.
- Designed for extensive mechanical life of up to 500,000 operations.
- Meets CSA, RoHS, UR, and VDE standards ensuring quality and compliance.
- Subminiature microswitch suitable for compact applications.
- Ideal for communication equipment, vending machines, security and medical devices.
Product Description
Panasonic AVT321461-A Short Hinge Lever Micro Switch is a subminiature, high precision switch designed for demanding industrial and commercial applications. Featuring a short hinge lever actuator and solder terminals, this micro switch supports a contact current of 100mA and ratings of 250V AC and 30V DC, ensuring reliable switching performance.
The switch is built to operate effectively in ambient conditions from -25°C up to 85°C, coupled with a robust mechanical life expectancy of 500,000 operations. Designed with flux-resistant construction and integrally molded terminals, it is resistant to contamination and provides secure mounting options including right angle, left angle, and PC board terminals.
This product complies with multiple international safety and quality standards such as CSA, RoHS, UR, and VDE, making it well suited for use in communication equipment, vending machines, security systems, data systems, and medical equipment.
The contact configuration is SPCO (Single Pole Change Over), allowing for versatile circuit designs. The compact subminiature size benefits integration in spatially constrained equipment without compromising durability or performance.
Panasonic’s AVT series is recognized for precise actuation and high reliability in industrial automation and electronic controls. This model's solder terminal type ensures ease of assembly in various electronic devices requiring precise micro switch functionality.
Featuring a short hinge lever actuator for precise actuation. Equipped with solder terminals for secure electrical connections. Configured as SPCO contact type for versatile switching. Operates reliably within temperature range from -25°C to 85°C.
Designed for extensive mechanical life of up to 500,000 operations. Meets CSA, RoHS, UR, and VDE standards ensuring quality and compliance. Subminiature microswitch suitable for compact applications. Ideal for communication equipment, vending machines, security and medical devices.
Constructed with flux-resistant materials and integrally molded terminals for durability. Explore the Electronics & Electricals category at EnvMart for a comprehensive selection of Micro Switches and related components.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model supports a contact current of 100mA, with voltage ratings of 250V AC and 30V DC.
It operates reliably within a temperature range of -25°C to 85°C.
This micro switch features a short hinge lever actuator for precise actuation.
It is designed for an extensive mechanical life of up to 500,000 operations.
This switch meets multiple standards including CSA, RoHS, UR, and VDE, ensuring quality and compliance.
The switch is equipped with solder terminals for secure electrical connections.
It has an SPCO (Single Pole Change Over) contact configuration, allowing for versatile circuit designs.
It is suitable for use in communication equipment, vending machines, security systems, data systems, and medical equipment.
The operating force required for actuation is 0.39N.
This model is classified as a subminiature microswitch, making it suitable for compact applications.
The country of origin for this micro switch is Thailand.
It is constructed with flux-resistant materials and integrally molded terminals to resist contamination and ensure durability.
