Panasonic Shielded Wirewound Surface Mount Inductor with Metal Composite Core 15μH ±20% 5.5A Idc ETQP5M

Panasonic ETQP5M shielded wirewound surface mount inductor features a metal composite core providing high thermal and vibration reliability. This inductor has an inductance rating of 15μH with ±20% tolerance and supports a maximum DC current of 5.5A, allowing for stable power handling in demanding electronic circuits.

The device operates up to a maximum temperature of 150°C, including self-generated heat, making it suitable for high-temperature environments such as automotive and industrial electronics. Its shielded construction minimizes electromagnetic interference, enhancing overall circuit performance.

The integral construction results in superior vibration resistance, reducing mechanical failures in harsh conditions. The low audible noise feature is ideal for noise-sensitive applications requiring clean signal filtering.

With a maximum DC resistance of 53.1mΩ and a high self-resonant frequency of 100kHz, this Surface Mount Inductor ensures efficient current flow with minimal losses. It complies with RoHS directives and the automotive AEC-Q200 standard, confirming its reliability and environmental compliance.

The physical dimensions are 8.5mm in length, 5.4mm in height, and 8mm in depth, packaged in tape & reel format to facilitate high-volume automated assembly. The product has a wirewound inductor construction style with 2 pins for surface mounting termination.

High heat resistance with operation up to 150°C including self heat. Shielded construction using metal composite core for excellent inductance stability. High vibration resistance with newly developed integral construction.

Low audible noise suitable for noise filtering in various drive circuitry. Maximum DC resistance of 53.1mΩ ensuring efficient current flow. Complies with automotive standard AEC-Q200 for reliability in automotive applications.

Surface mount package with dimensions 8.5mm length, 5.4mm height, and 8mm depth. Packaging type: Tape & Reel facilitating efficient automated PCB insertion. Inductor construction is wirewound with 2 pins for surface mounting.

RoHS compliant ensuring lead-free environmental standards.

This inductor is suitable for industrial, automotive, and laboratory electronic applications where high reliability and performance are critical. It is used in power supply filtering, noise suppression, and signal conditioning circuits.
