Panasonic Black Grey Surface Mount Tactile Switch Push Plate SPST 50mA 12V DC EVQP7J01P
Specifications
| Country of Origin | China |
|---|---|
| Brand | Panasonic |
| Height | 1.35mm |
| Model | EVQP7J01P |
| Mount Type | Surface |
| Series | EVQP |
| Contact Configuration | SPST |
| Terminal type | Straight |
| Switch Operation | Push-On |
| Actuator Colour | Black, Grey |
| Contact DC Voltage | 12V dc |
| Actuator Style | Push Plate |
| Actuator Orientation | Straight |
| Switch Contact Current | 50mA |
| Operating Force | 1.6N |
| Mechanical Life | 100000Cycles |
| Panasonic Black, Grey Tactile Switch Push Plate, SPST 50mA 12 V dc, SurfaceBrand | Panasonic |
Key Features
- The push plate actuator offers a straight orientation with enhanced strength.
- Its low operating force of 1.6 N ensures easy tactile feedback.
- The switch supports a mechanical life of 100000 cycles.
- Compact height of 1.35 mm suits portable electronic equipment.
- Operates reliably within -20℃ to +70℃ temperature range.
- Terminal type is straight for secure PCB mounting.
- Designed as snap action push-on type for efficient switching.
- Actuator colors are black and grey to suit various designs.
Product Description
Panasonic EVQP7J01P is a high-quality black and grey tactile switch push plate designed for reliable, low current SPST switching in electronic devices. It operates at 50mA DC current and 12V DC voltage, ideal for surface mount applications requiring a compact and durable solution.
This tactile switch features a straight push plate actuator with enhanced strength to provide precise and responsive operation. The mechanical life of 100000 cycles ensures long-lasting performance in electronic circuits, particularly in portable equipment and control panels.
The switch uses a straight terminal type and snap action push-on operation mode, enabling easy installation and dependable contact switching. With a height of only 1.35 mm and an operating force of 1.6 Newtons, it delivers optimal tactile feedback with minimal effort.
Designed to operate within a wide temperature range from -20°C up to +70°C, the EVQP7J01P is suitable for various industrial, commercial, and consumer electronic applications requiring compact tactile input devices.
The push plate actuator has a straight orientation providing consistent operation. Black and grey actuator colors accommodate different design needs. Surface mount configuration enables space-saving PCB assembly. Mechanical durability rated at 100000 cycles under normal use conditions.
Operating force of 1.6N provides reliable tactile feedback. Electrical rating supports resistive loads up to 50mA at 12V DC. Compact height of 1.35mm for sleek device integration. Manufactured in China under Panasonic's quality standards.
This Panasonic tactile switch EVQP7J01P is widely used in electronics industries including consumer electronics, automotive controls, industrial automation, and instrumentation. Its robust design and consistent performance make it a preferred choice for reliable discrete input switching applications.
Explore Panasonic’s range of Tactile Switches and other switch components at EnvMart for industrial and electronic automation solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The tactile switch operates at a contact DC voltage of 12V and supports a contact current of 50mA.
This model has a mechanical life rated at 100,000 cycles under normal use conditions.
The operating force for this tactile switch is 1.6 Newtons, providing reliable tactile feedback with minimal effort.
The height of this switch is 1.35 mm, making it suitable for compact electronic devices.
It features a straight terminal type, which allows for secure PCB mounting.
The actuator style is a push plate with a straight orientation, designed for efficient switching.
This model operates reliably within a temperature range of -20°C to +70°C.
The actuator is available in black and grey colors to suit various design needs.
It has a Single Pole Single Throw (SPST) contact configuration.
This switch is widely used in consumer electronics, automotive controls, industrial automation, and instrumentation.
The switch is designed for surface mounting, enabling space-saving PCB assembly.
The EVQP7J01P is part of the EVQP series of tactile switches from Panasonic.
