Panasonic Tactile Switch Push Plate, SPST, Straight Terminal, 50mA 12V DC, Black/Grey, Surface Mount EVQP7J01P
Specifications
| Country of Origin | China |
|---|---|
| Brand | Panasonic |
| Height | 1.35mm |
| Model | EVQP7J01P |
| Mount Type | Surface |
| Series | EVQP |
| Contact Configuration | SPST |
| Terminal type | Straight |
| Switch Operation | Push-On |
| Actuator Colour | Black, Grey |
| Contact DC Voltage | 12V dc |
| Actuator Style | Push Plate |
| Actuator Orientation | Straight |
| Switch Contact Current | 50mA |
| Operating Force | 1.6N |
| Mechanical Life | 100000Cycles |
| Panasonic Black, Grey Tactile Switch Push Plate, SPST 50mA 12 V dc, SurfaceBrand | Panasonic |
Key Features
- Single pole single throw (SPST) contact configuration for reliable switching.
- Rated for 50mA at 12V DC, suitable for low-power circuits.
- Black and grey push plate actuator with straight orientation and surface mount design.
- Mechanical life span of up to 100,000 cycles ensures durability.
- Operating force of 1.6N provides tactile feedback during actuation.
- Compact height of 1.35mm allows for integration in space-critical applications.
- Ideal for portable electronic equipment and industrial control panels.
Product Description
Panasonic EVQP7J01P tactile switch push plate features a robust single pole single throw (SPST) contact configuration, optimized for straightforward reliability and efficiency. The unit is rated for a maximum contact current of 50mA at 12V DC, ensuring safe operation in low-voltage electronic applications.
Single pole single throw (SPST) contact configuration for clean switching action. Rated for 50mA at 12V DC, supporting resistive load applications. Terminal type is straight, compatible with surface mount installation. Push plate actuator in black and grey, offering enhanced visual identification and mechanical strength.
Push-on switch operation with tactile feedback; operating force is measured at 1.6 Newtons. Mechanical life exceeds 100,000 cycles, boosting product longevity. Very compact height at just 1.35mm, ideal for densely packed circuit boards.
Suitable for portable electronic devices, control panels, and industrial automation systems.
The EVQP7J01P includes a straight actuator orientation and a surface mount type, making it easy to implement in production environments. It operates reliably across temperatures from -20°C to +70°C, making it appropriate for both consumer electronics and industrial environments.
Panasonic’s tactile switches are widely used in keyboard and keypad switches, portable devices, and industrial instrumentation. Their compact design, high durability, and enhanced tactile response provide optimal usability and feedback for frequent operation cycles.
This switch belongs to the EVQP series, which is renowned for its robustness in mechanical strength and stable electrical performance. The enhanced push plate strength supports efficient machinery insertion, thus speeding up production lines and assembly operations.
Industrial and laboratory contexts include application in automation panels, sensor circuits, and electronic control systems. The tactile feedback ensures positive operation, reducing user error and improving system reliability.
Browse more Panasonic switch products and Tactile Switches on EnvMart to meet your industrial and electronics design requirements.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The tactile switch is rated for a maximum contact current of 50mA at 12V DC, suitable for low-power circuits.
This model has a mechanical life span of up to 100,000 cycles, ensuring longevity in operation.
It features a single pole single throw (SPST) contact configuration for reliable switching action.
The operating force is measured at 1.6 Newtons, providing tactile feedback during actuation.
The switch has a compact height of 1.35mm, making it suitable for space-critical applications.
This model is designed for surface mount installation, facilitating easy integration into circuit boards.
The actuator is available in black and grey, enhancing visual identification and mechanical strength.
It operates reliably across temperatures from -20°C to +70°C, suitable for various environments.
This switch is suitable for portable electronic devices, control panels, and industrial automation systems.
It features a straight terminal type, compatible with surface mount installation.
The switch operates on a push-on mechanism, allowing for straightforward actuation.
This switch belongs to the EVQP series, known for its robustness and stable electrical performance.
