Wurth Elektronik WR-PHD Series Straight Through Hole PCB Socket, 6-Contact, 1 Row, 2.54 mm Pitch, 3A, 500V 61300611821
Specifications
| Country of Origin | Taiwan |
|---|---|
| Voltage | 500V |
| Brand | Wurth Elektronik |
| Orientation | Straight |
| Current | 3A |
| Mount Type | Through Hole |
| Housing Material | Polybutylene Terephthalate |
| Contact Material | Copper Alloy |
| Series | WR-PHD |
| Termination Type | Solder |
| Maximum Operating Temperature | 105°C |
| Sub Type | THT Female Single Row Straight Socket |
| Minimum Operating Temperature | -40°C |
| Number of Rows | 1 |
| Pitch | 2.54mm |
| Contact Plating | Gold |
| Number of Contacts | 6 |
| Contact Gender | Female |
| Connector System | Board-to-Board |
Key Features
- Features a straight through hole mount with a single row of 6 contacts.
- Contacts are gold plated copper alloy for enhanced conductivity and corrosion resistance.
- Constructed with a black UL94-V0 rated polybutylene terephthalate insulator for flame resistance.
- Supports a current rating of 3 Amps and voltage rating up to 500 Volts.
- Designed for solder termination on printed circuit boards with a pitch of 2.54 mm.
- Operates reliably within a temperature range of -40°C to 105°C.
- Suitable for industrial electronic assembly, power connectors, and PCB interconnect applications.
Product Description
The Wurth Elektronik 61300611821 WR-PHD Series Straight Through Hole PCB Socket is a high-quality 6-contact, single row connector designed for board-to-board applications requiring robust and reliable connections. Manufactured with a black UL94-V0 rated polybutylene terephthalate housing, this socket ensures superior flame resistance and durability.
The gold plated copper alloy contacts deliver excellent conductivity and corrosion resistance, making it suitable for demanding electronic environments. The 2.54 mm pitch spacing enables easy integration into standard PCB designs, with a solder termination type ideal for through-hole mounting.
This PCB socket supports a maximum current of 3 Amps and operates safely at voltages up to 500 Volts. It is engineered to perform within a wide operating temperature range from -40°C to 105°C, ensuring stable operation in diverse industrial and electronic settings.
Applications include use in electronic assembly lines, industrial power connectors, automation equipment, and any system requiring secure board-to-board connection solutions. Features a straight through hole mount with a single row of 6 contacts.
Contacts are gold plated copper alloy for superior conductivity and longevity. Black polybutylene terephthalate housing with UL94-V0 flammability rating. Current rating: 3 Amps; Voltage rating: 500 Volts. Solder termination suitable for through hole mounting on PCBs.
Operating temperature range from -40°C to 105°C. Designed for industrial electronics, power connectors, and PCB interconnects. Explore the full range of Wurth Elektronik PCB Sockets and connectors to find the ideal components for your electronic manufacturing needs on EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum current rating for this socket is 3 Amps.
This model can safely handle voltages up to 500 Volts.
The pitch size of the contacts is 2.54 mm.
The housing of this socket is made from polybutylene terephthalate.
This PCB socket uses a solder termination type for mounting on printed circuit boards.
The operating temperature range for this unit is from -40°C to 105°C.
This PCB socket has 6 contacts in a single row configuration.
The contacts are made of gold plated copper alloy for enhanced conductivity and corrosion resistance.
The orientation of this PCB socket is straight through hole.
This socket is suitable for industrial electronic assembly, power connectors, and PCB interconnect applications.
The country of origin for this product is Taiwan.
This socket utilizes a board-to-board connector system.
