TDK 1210 Shielded Wirewound Surface Mount Inductor with Ferrite Core 680μH ±10% 25mA NLFV32T-681K-EF

TDK's NLFV32T-681K-EF is a 1210 size shielded wirewound Surface Mount Inductor designed with a ferrite core, offering an inductance of 680μH with ±10% tolerance and a maximum DC current rating of 25mA. This inductor is engineered to provide effective magnetic shielding by integrating ferrite powder in its molding resin, reducing electromagnetic interference and enhancing circuit stability.

Its compact dimensions (length 3.2mm, height 2.2mm, depth 2.5mm) make it an excellent choice for space-constrained designs. The inductor supports a wide operating temperature range from -40°C to 105°C, including self-temperature rise, ensuring reliable operation in diverse environments.

The wirewound construction combined with a molded resin casing delivers mechanical and thermal robustness, suited for demanding applications. With a maximum DC resistance of 22.2Ω and self-resonant frequency of 2.52MHz, it performs efficiently in filtering and decoupling circuits.

This component complies with RoHS standards and is made in Japan, indicating superior manufacturing quality. The NLFV32T-681K-EF inductor is widely applied in smart meters, audio-visual equipment, xDSL systems, mobile base stations, and other communication infrastructure electronics, as well as various industrial equipment.

The inductor offers reliable shielding for reduced electromagnetic interference. It is designed for surface mount technology with a compact 1210 package size. Operating temperature range spans from -40°C to 105°C, suitable for harsh environments.

The device has a maximum DC resistance of 22.2Ω ensuring stable performance. Its wirewound construction and molded resin type enhance durability and thermal stability. This inductor is ideal for smart meters, AV equipment, xDSL, communications infrastructure, and industrial applications.

It is RoHS compliant and manufactured in Japan, assuring quality and regulatory adherence. Explore EnvMart’s Electronics & Electricals category to find a comprehensive selection of inductors and other surface mount passive components.
