TDK 1210 Shielded Wirewound Surface Mount Inductor with Ferrite Core 15 μH ±10% 140 mA Idc NLFV32T-150K-EF

TDK NLFV32T-150K-EF is a 1210 size shielded wirewound surface mount inductor incorporating a ferrite core designed for decoupling circuits. It provides an inductance value of 15 μH with a tolerance of ±10% and handles a maximum DC current of 140 mA. The device features a resin molded exterior with ferrite powder ensuring magnetic shielding and enhanced electrical performance. This inductor operates reliably within a temperature range of -40°C to 105°C, including self-temperature rise conditions.

Constructed with wirewound technology, this inductor has a maximum DC resistance of 360 mΩ and a maximum self-resonant frequency of 2.52 MHz. It comes in a 1210 package case measuring 3.2 mm in length, 2.2 mm in height, and 2.5 mm in depth, making it compact and suitable for dense PCB layouts. The termination style is surface mount to facilitate modern SMT assembly processes.

This component conforms to RoHS standards, ensuring compliance with environmental regulations. It is supplied in tape and reel packaging, allowing for efficient automated placement during PCB assembly. The NLFV-EF series is well-suited for applications such as smart meters, audio-visual equipment, xDSL systems, mobile base stations, and various industrial communication devices. Designed and made in Japan, it offers superior quality and reliability for demanding electronic environments.

This inductor features a compact 1210 package size. The core material is ferrite, providing effective magnetic shielding. It supports an operating temperature range from -40°C to 105°C. The component has a maximum DC resistance of 360 mΩ.

It is manufactured with wirewound construction for enhanced reliability. The product is RoHS compliant, ensuring environmental safety. Packaging is supplied on tape and reel, ideal for automated assembly. Ideal for use in smart meters, AV equipment, xDSL, mobile base stations, and industrial communication devices.
