TDK 6045 Shielded Wirewound Surface Mount Inductor with Ferrite Core 220 μH ±20 % 570 mA Idc CLF6045NI-D

TDK CLF6045NI-D 6045 Shielded Wirewound Surface Mount Inductor features a ferrite core and provides an inductance of 220 μH with ±20% tolerance. It supports a maximum DC current of 570 mA and has a maximum DC resistance of 720 milliohms. This component is built in a shielded wirewound construction that ensures high mechanical robustness and reduces electromagnetic interference, making it suitable for demanding industrial and automotive environments.

The inductor operates within a temperature range of -55°C to 150°C, meeting the AEC-Q200 automotive standard for quality and reliability. Packaged in a 6045 surface mount case, its dimensions are 6.3 mm in length, 4.5 mm in height, 6 mm in depth, and 6 mm in diameter, optimized for space-constrained designs.

TDK's CLF6045NI-D is ideal for applications requiring efficient power supply filtering, including DC/DC converters, automotive electronics circuits, and coupling or decoupling in signal processing. Its ferrite core enhances magnetic performance, and the shielded design minimizes crosstalk and EMI, ensuring signal integrity.

This part is designed for lead-free reflow soldering, supporting environmentally compliant manufacturing processes. Furthermore, packaging is provided on tape and reel, facilitating automated assembly line integration.

Constructed with a ferrite core for enhanced magnetic performance. Shielded wirewound design reduces EMI interference effectively. Compact 6045 package suitable for surface mount applications. Operates reliably between -55°C and 150°C temperature range.

Maximum DC resistance of 720 milliohms for low power losses. Designed to comply with automotive standard AEC-Q200 for quality assurance. Supports lead-free reflow soldering for environmental compliance. Applications include DC/DC converters, automotive electronics, and voltage filtering.
