TDK Shielded Wirewound Surface Mount Inductor with Ferrite Core 6.8 μH ±20 % 530 mA Idc Q:15 NLCV32T-6R8M-EF

TDK NLCV32T-6R8M-EF is a shielded wirewound surface mount inductor featuring a ferrite core with an inductance value of 6.8 μH and ±20 % tolerance. The inductor is designed to handle a maximum DC current of 530 mA, offering reliable performance for decoupling circuits and electromagnetic interference suppression.

Encapsulated in a 1210 package case, the inductor measures 3.2 mm in length, 2.2 mm in height, and 2.5 mm in depth, making it suitable for compact surface mount technology (SMT) applications. Its resin-moulded construction ensures durability and stability across an operating temperature range from -40°C to 105°C, including self-temperature rise during operation.

With a minimum quality factor of 15 and a maximum self-resonant frequency of 38 MHz, this inductor delivers efficient inductance and low losses at high frequencies. The device’s maximum DC resistance is 351 mΩ, minimizing power dissipation in power-sensitive electronics.

The inductor is RoHS compliant and includes shielding to reduce electromagnetic interference, making it well-suited for electronic devices requiring noise reduction. Common industrial and commercial applications include smart meters, audio-visual equipment, xDSL modems, mobile base stations, and various communications infrastructure machinery.

Manufactured in Japan, this component meets rigorous quality and reliability standards necessary for demanding electronic applications that require stable inductance and low electromagnetic interference.

Features a maximum DC current rating of 530 mA. Constructed with a ferrite core and moulded resin for durability. Suitable for surface mount applications with a 1210 package case size. Operates reliably within a temperature range of -40°C to 105°C.

Provides a minimum quality factor of 15 and a maximum self-resonant frequency of 38 MHz. Offers low DC resistance at 351 mΩ to minimize power loss. RoHS compliant and equipped with shielding to reduce electromagnetic interference.

Ideal for use in smart meters, AV equipment, xDSL, communications infrastructure, and industrial electronics. Explore more Surface Mount Inductors and electronic components at EnvMart for your industrial, laboratory, and commercial electronics needs.
